D-Link DAP-E3620OU wireless access point 3600 Mbit/s White Power over Ethernet (PoE)

2.4 / 5 GHz, 802.11be/ax/ac/n/g/b/a, 2x 2.5-Gigabit Ethernet PoE LAN, 802.3at PoE, 304 x 181 x 88 mm

Key Features

• High-speed BE3600 dual-band Wi-Fi 7 connectivity
• OFDMA + MU-MIMO boosts multi-user efficiency
• 2.5GbE uplink eliminates wired bottlenecks
• Single-cable PoE+ deployment for faster installation
• Optimized RF design for stable outdoor coverage
• Enterprise-grade WPA3 security protection
• Traffic segmentation via SSID-to-VLAN mapping
• Rugged weather-resistant for harsh environments
• Centralized management through Nuclias Unity
• Easy management via Nuclias HW/SW controllers

Description

Wi-Fi 7 Technology
Dual-band Wi-Fi 7 (802.11be), BE3600 class (2×2 + 2×2), delivering lower latency and higher efficiency for multi-user traffic

Rugged Outdoor Design
IP67-rated weatherproof design for reliable outdoor deployment and built for harsh environments with reduced maintenance

Customizable Captive Portal
Per-SSID captive portal support enables branded guest access, promotions, and flexible login workflow

VLAN per SSID
Each SSID to a dedicated VLAN for traffic segmentation, enabling simple separation of networks through policy-based control

Protection and Mounting
Flexible mounting options combined with durable protection ensure reliable installation and long-term performance

Centralized Management
Centralized management through Nuclias Unity or Nuclias hardware/software controllers (DNH-1000, DNC-5000)

Faster Wireless,
Better Business Experiences
- Experience next-generation dual-band Wi-Fi 7 (BE3600 class) built for modern business networks, delivering faster speeds, lower latency, and more reliable connectivity.
- With up to 5 GHz up to 2882 Mbps and 2.4 GHz up to 688 Mbps, businesses gain high-capacity performance for productivity, collaboration, and everyday wireless connectivity.
- Advanced 4K-QAM improves throughput and device capacity, while Multi-Link Operation (MLO) enhances responsiveness and reliability in busy environments.
- Designed for resort garden, school campus, public square and outdoor application,
- it provides stable, scalable wireless performance for staff, guests, and connected
- devices-helping improve productivity, user experience, and operational efficiency.

Outdoor Wi-Fi 7 That Braves the Elements
Engineered for harsh environments, the DAP-E3620OU delivers blazing Wi-Fi 7 (BE3600) speeds inside a fully weatherproof chassis built for year-round reliability. Its IP67-rated enclosure and wide temperature tolerance keep connections stable through pouring rain, scorching heat, and freezing cold. With a 2.5GbE PoE uplink, you can place it anywhere without worrying about power outlets—perfect for campuses, factories, public plazas, and outdoor dining areas.

Easy Installation & High-Speed Deployment
The DAP-E3620OU features a single-cable 2.5GbE and PoE+ connection, delivering both power and high-speed data through one Ethernet cable. This simplifies installation, reduces cabling complexity, and enables more flexible device placement in outdoor environments where power access may be limited.

With high-speed 2.5GbE backhaul support, the wired network can fully support Wi-Fi 7 performance without bottlenecks, ensuring smooth connectivity for bandwidth-intensive applications and wireless deployments.

Simplified Centralized Network Management
- The DAP-E3620OU integrates seamlessly with D-Link Nuclias Unity and Nuclias hardware and software controllers, including the DNH-1000 and DNC-5000, to streamline Wi-Fi management for growing business networks.
- Through an intuitive dashboard, IT teams can quickly provision access points, enforce SSID and VLAN policies, deploy firmware updates, and monitor network health across sites. Centralized visibility and configuration simplify deployment, accelerate troubleshooting, and reduce routine maintenance, making it easy to scale from small installations to enterprise environments with consistent performance and security.

Specifications

Performance
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Maximum data transfer rate	3600 Mbit/s
Ethernet LAN data rates	1000,2500 Mbit/s
Frequency band	2.4/5 GHz
Web-based management	Yes
Reset button	No
Networking standards	IEEE 802.11be, IEEE 802.11ax, IEEE 802.3at, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Features
6 GHz	No
2.4 GHz	Yes
5 GHz	Yes
Wireless isolation	Yes
Maximum data transfer rate	3600 Mbit/s
Ethernet LAN data rates	1000,2500 Mbit/s
Frequency band	2.4/5 GHz
Networking standards	IEEE 802.11be, IEEE 802.11ax, IEEE 802.3at, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	2882 Mbit/s
Security
Security algorithms	WPA, WPA2, WPA3, AES, AES-CCMP, WEP, 802.1x RADIUS, SNMP
MAC address filtering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Service Set Identifier (SSID) features	SSID broadcast, Multiple SSIDs
Management features
Web-based management	Yes
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	2
Power
Power consumption (max)	17.04 W
Power over Ethernet (PoE)	Yes
Design
Placement	Pole, Wall
Reset button	No
LED indicators	Power, Link, Status, WLAN
Product colour	White
Antenna
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	6 dBi
Weight & dimensions
Width	181 mm
Depth	88 mm
Height	304 mm
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	-30 - 55 °C
Storage temperature (T-T)	-40 - 70 °C
Storage relative humidity (H-H)	5 - 95%
