D-Link DAP-E3620 wireless access point 2882 Mbit/s White Power over Ethernet (PoE)

D-Link DAP-E3620 BE3600 Wi-Fi 7 Dual-band POE Access Point

Key Features

• Affordable Wi-Fi 7 upgrade for everyday business use
• BE3600 dual-band Wi-Fi for modern teams and offices
• Reliable performance in environments
• 2.5GbE uplink for faster end-to-end connectivity
• Simple PoE+ deployment with one-cable setup
• Enterprise-grade security with WPA3 support
• Easy traffic separation with VLAN-to-SSID mapping
• Built-in captive portal for guest access
• Flexible deployment modes for multiple scenarios
• Centralized management for easy operations

Description

Wi-Fi 7 Technology
Dual-band Wi-Fi 7 (802.11be), BE3600 class (2×2 + 2×2), delivering lower latency and higher efficiency for multi-user traffic

Easy Installation
Flexible ceiling or wall mounting for SMB deployments, while PoE+ simplifies cabling and accelerates installation

Customizable Captive Portal
Per-SSID captive portal support enables branded guest access, promotions, and flexible login workflow

VLAN per SSID
Each SSID to a dedicated VLAN for traffic segmentation, enabling simple separation of networks through policy-based control

Advanced Security
Supports WPA3-Personal/WPA3-Enterprise, 802.1X, and ACL-based access control to help reduce unauthorized access

Centralized Management​
Centralized management through Nuclias Unity or Nuclias hardware/software controllers (DNH-1000, DNC-5000)

Faster Wi-Fi 7 for
Better Business Experiences
Dual-band Wi-Fi 7 (802.11be, BE3600 class) built for business environments — more speed, less latency, more devices.

- 5 GHz up to 2882 Mbps + 2.4 GHz up to 688 Mbps — combined throughput for demanding workloads, video collaboration, and dense device environments.
- Multi-Link Operation (MLO) uses both bands simultaneously, cutting latency and keeping connections stable when one band is congested.
- 4096-QAM enables faster data transmission for smoother streaming, gaming, and downloads.
- Designed for offices, hospitality, retail, and SMB deployments, it provides stable, scalable wireless performance for staff, guests, and connected devices—helping improve productivity, user experience, and operational efficiency.

Flexible Deployment for Any Network Need
Deploy in the mode that fits your infrastructure. Switch between access point, wireless bridge, or hybrid coverage without additional hardware.

Access Point Mode
Standard Wi-Fi coverage for wired networks — offices, classrooms, and public hotspots.

WDS with Access Point Mode (Wireless bridging + local coverage)
Extends coverage wirelessly while broadcasting a local SSID — connects floors or buildings without new cabling.

WDS Mode (No AP Broadcasting)
Pure wireless backhaul between two wired networks — no local SSID. Ideal for linking switches, cameras, or servers across sites.

High-Speed 2.5GbE PoE+ Uplink — No Wired Bottleneck

- Full Wi-Fi 7 throughput — the 2.5GbE uplink matches wireless capacity so your wired network never limits wireless performance.
- Single cable for power and data — IEEE 802.3at PoE+ eliminates the need for a separate power adapter, simplifying installation anywhere a switch port can reach.

Specifications

Performance
2.4 GHz	Yes
5 GHz	Yes
Auto Wireless Distribution System (WDS)	Yes
Syslog	Yes
Maximum data transfer rate	2882 Mbit/s
Ethernet LAN data rates	2500 Mbit/s
Frequency band	2.4 - 5.85 GHz
Web-based management	Yes
Reset button	No
Networking standards	IEEE 802.11be, IEEE 802.11ax, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3at
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Features
6 GHz	No
2.4 GHz	Yes
5 GHz	Yes
Maximum data transfer rate	2882 Mbit/s
Ethernet LAN data rates	2500 Mbit/s
Frequency band	2.4 - 5.85 GHz
Networking standards	IEEE 802.11be, IEEE 802.11ax, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3bz, IEEE 802.3at
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Maximum data transfer rate (2.4 GHz)	688 Mbit/s
Maximum data transfer rate (5 GHz)	2882 Mbit/s
Security
Auto Wireless Distribution System (WDS)	Yes
Security algorithms	WPA, WPA2, WPA3, 802.1x RADIUS, AES, WPA-Personal, WPA-Enterprise, WPA3-Personal, WPA3-Enterprise
MAC address filtering	Yes
Remote Authentication Dial-In User Service (RADIUS)	Yes
Service Set Identifier (SSID) features	SSID broadcast
Management features
Syslog	Yes
Web-based management	Yes
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power
Power consumption (max)	14.17 W
Input current	2.5 A
Power over Ethernet (PoE)	Yes
DC voltage range	12 V
Design
Placement	Ceiling
Reset button	No
LED indicators	Power, Status, Link, Wi-Fi
Product colour	White
Antenna
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	4 dBi
Weight & dimensions
Width	186 mm
Depth	186 mm
Height	37 mm
Weight	550 g
Packaging data
AC adapter included	No
Packaging content
AC adapter included	No
Operational conditions
Operating relative humidity (H-H)	10 - 90%
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 65 °C
Storage relative humidity (H-H)	5 - 95%
