20 Gbps, 1 x GbE RJ45, 3 x 10 GbE RJ45, Rack mount (1U), 18W, 442.4 x 120 x 43.7 mm
Description
10 GbE WAN Switch linking two Shadow Mode High Availability UniFi Gateways to a single ISP.
Specifications
| Management features |
|---|
| Reset button |
Yes |
| Ports & interfaces |
|---|
| Basic switching RJ-45 Ethernet ports quantity |
1 |
| Basic switching RJ-45 Ethernet ports type |
Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity |
1 |
| Power connector |
AC/DC |
| 10G Ethernet (copper) ports quantity |
3 |
| Power cables quantity |
2 |
| Network |
|---|
| 10G support |
Yes |
| Data transmission |
|---|
| Switching capacity |
20 Gbit/s |
| Forwarding rate |
15 Mpps |
| Throughput |
10 Gbit/s |
| Design |
|---|
| Reset button |
Yes |
| Rack mounting |
Yes |
| Product colour |
Grey |
| Form factor |
1U |
| LED indicators |
Network, System |
| Housing material |
SGCC |
| Power |
|---|
| Power consumption (max) |
18 W |
| Power supply included |
Yes |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power source |
AC/DC |
| Power connector |
AC/DC |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) |
No |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-5 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
442.4 mm |
| Depth |
120 mm |
| Height |
43.7 mm |
| Weight |
2.3 kg |
| Packaging content |
|---|
| Rack mount kit |
Yes |
| Cables included |
Power |
| Technical details |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), Industry Canada (IC), National Defense Authorization Act (NDAA) |
| Packaging data |
|---|
| Rack mount kit |
Yes |
| Cables included |
Power |
