Ubiquiti UISP Wave Access Point 5400 Mbit/s White
SAVE 25%

Ubiquiti

Ubiquiti UISP Wave Access Point 5400 Mbit/s White

Read reviews
SKU: WAVE-AP
Your price $1,001.57
List price $1,331.10 Save $329.53
GST included · AUD
New Sealed in box Australian stock Warehouses in Sydney, Melbourne, Brisbane, Adelaide and Perth Delivery only - Pickup unavailable 2-5 Business days metro delivery. Australian manufacturer Warranty

In stock — ready to ship

Estimate shipping

Enter an Australian postcode for a quick estimate.

Final shipping options and price are confirmed at checkout.

Need bulk pricing for schools or councils? Request a quote via Contact Us.

60 GHz PtMP access point

Key Features

  • 5 GHz backup radio
  • Supported stations and distances:
  • – Wave Long-Range: up to 8 km
  • – Wave Nano: up to 5 km
  • WAN Ports: (1) 10G SFP+, (1) 2.5GbE
  • Integrated GPS antenna

Description

60 GHz PtMP access point powered by Wave Technology.

The Wave Access Point can connect up to 15 stations and deliver up to 5.4 Gbps total throughput (2.7 Gbps duplex). It is equipped with a high-performance 5 GHz backup radio to ensure uninterrupted connection, as well as a Bluetooth radio to simplify setup in the UISP® Mobile app.

Specifications

Data transmission
Maximum data transfer rate 5400 Mbit/s
Antenna
Antenna gain level (max) 24 dBi
Antenna type Internal
Wireless LAN features
Frequency band 57 - 71 GHz
Modulation 16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, QPSK
Antenna gain level (max) 24 dBi
Antenna type Internal
Network
Ethernet LAN data rates 100,1000,2500,10000 Mbit/s
Full duplex Yes
Frequency band 57 - 71 GHz
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
Security
Security algorithms AES, WPA2-PSK
Management features
Management protocols SNMP
Web-based management Yes
LED indicators Yes
Features
Reset button Yes
International Protection (IP) code IPX6
LED indicators Yes
Internal memory 512 MB
Product colour White
Power
Power consumption (max) 24 W
Power over Ethernet (PoE) Yes
Operational conditions
Operating temperature (T-T) -40 - 60 °C
Operating relative humidity (H-H) 5 - 95%
Certificates
Certification FCC, IC
Technical details
Internal memory 512 MB
Product colour White
Sustainability compliance Yes
Compliance certificates CE
Weight & dimensions
Weight 2.3 kg
Width 212 mm
Depth 187 mm
Height 205 mm
Processor
Processor frequency 1400 MHz
Brand
Ubiquiti
SKU
WAVE-AP
