48V DC 1.25A, 100—240V AC, 50/60Hz, 65 kHz
Key Features
- Delivers up to 60W of PoE++
- Even more power for UA Hub, G4 PTZ, and other PoE++ devices
- Surge, peak pulse, and overcurrent protection
- Contains RJ45 data input, AC cable with earth ground, and PoE++ output
- LED indicator for status monitoring
Description
An adapter that can power UniFi PoE++ devices with wireless mesh applications, or offload PoE switch power dependencies.
Specifications
| Network |
|---|
| Networking standards |
IEEE 802.3at |
| Power over Ethernet (PoE) |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Power over Ethernet (PoE) voltage |
48 V |
| Features |
|---|
| Product colour |
White |
| Networking standards |
IEEE 802.3at |
| Certification |
CE, FCC, IC, UL, UKCA, KC, CCC, RoHS |
| Power |
|---|
| Output power |
60 W |
| Output current |
0.65 A |
| Power over Ethernet (PoE) voltage |
48 V |
| Input voltage |
100-240 V |
| Input frequency |
50/60 Hz |
| Input current |
1.25 A |
| DC output voltage |
48 V |
| Certificates |
|---|
| Certification |
CE, FCC, IC, UL, UKCA, KC, CCC, RoHS |
| Compliance certificates |
CCC, CE, Federal Communications Commission (FCC), KC, RoHS, UKCA |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Sustainability certificates |
UL ECOLOGO |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-30 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating temperature (T-T) |
32 - 104 °F |
| Weight & dimensions |
|---|
| Weight |
210 g |
| Width |
63 mm |
| Depth |
34 mm |
| Height |
106 mm |
| Packaging content |
|---|
| Power cord included |
Yes |
| Number of products included |
1 pc(s) |
| Technical details |
|---|
| Power over Ethernet (PoE) |
Yes |
| Operating temperature (T-T) |
32 - 104 °F |
| Number of products included |
1 pc(s) |
| Input voltage |
100-240 V |
| Input frequency |
50/60 Hz |
| Input current |
1.25 A |
| Ethernet interface type |
Gigabit Ethernet |
| Sustainability compliance |
Yes |
| Sustainability certificates |
UL ECOLOGO |
| Compliance certificates |
CCC, CE, Federal Communications Commission (FCC), KC, RoHS, UKCA |
