UniFi AP AC PRO (Version-2) 802.11ac Dual Radio Indoor/Outdoor Access Point, 122m max, 1300Mbps Throughput
Key Features
- Unlimited Indoor/Outdoor AP Scalability in a Unified Management System
- Breakthrough Speeds up to 1300 Mbps in the 5 GHz Band
- Intuitive UniFi Controller Software
Description
The UniFi AC Pro AP features the latest Wi-Fi 802.11ac, 3×3 MIMO technology in a refined industrial design and is ideal for deployment of maximum‑performance wireless networks.
Sporting a weatherproof design, the UniFi AC Pro AP features simultaneous, dual-band, 3×3 MIMO technology and convenient 802.3af PoE/802.3at PoE+ compatibility.
Specifications
| Performance |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Maximum data transfer rate |
1750 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Number of users |
250 user(s) |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Certification |
CE, FCC, IC |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Features |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Wi-Fi Multimedia (WMM)/(WME) |
Yes |
| Maximum data transfer rate |
1750 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Number of users |
250 user(s) |
| VLAN support |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.1Q, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u |
| Cabling technology |
10/100/1000Base-T(X) |
| Dynamic Frequency Selection (DFS) |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
450 Mbit/s |
| Maximum data transfer rate (5 GHz) |
1300 Mbit/s |
| Security |
|---|
| Security algorithms |
AES, TKIP, WEP, WPA, WPA-Enterprise, WPA-PSK, WPA2 |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
2 |
| Cabling technology |
10/100/1000Base-T(X) |
| Power |
|---|
| Power consumption (max) |
9 W |
| Output voltage |
44 - 57 V |
| Power over Ethernet (PoE) |
Yes |
| Design |
|---|
| Placement |
Ceiling, Wall |
| Product colour |
White |
| Certification |
CE, FCC, IC |
| Antenna |
|---|
| Antenna type |
Internal |
| Antennas quantity |
3 |
| Antenna gain level (max) |
3 dBi |
| Antenna features |
Integrated antenna |
| Software |
|---|
| Dynamic Frequency Selection (DFS) |
Yes |
| Weight & dimensions |
|---|
| Width |
196.7 mm |
| Depth |
196.7 mm |
| Height |
35 mm |
| Weight |
350 g |
| Packaging data |
|---|
| Mounting kit |
Yes |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-10 - 70 °C |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
