WiFi 7 (802.11a/b/g/n/ac/ax/be), 6 GHz, IP67, 465m2 (5000 ft2), 2.5 GbE RJ45, PoE+, UV-stabilized polycarbonate, aluminum alloy, max 21W
Key Features
- WiFi 7
- 6 spatial streams
- 465 m² (5,000 ft²) open space coverage with the integrated directional super antenna
- Software-switchable from internal directional to included external omni antennas
- 300+ connected devices
- Powered using PoE+
- 2.5 GbE uplink
- Versatile wall and pole mounting
- Weatherproof (outdoor exposed)
Description
All-weather IP67 WiFi 7 AP with 6 spatial streams, integrated directional super antenna, and articulation mounting bracket.
Specifications
| Performance |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Maximum data transfer rate |
8600 Mbit/s |
| Ethernet LAN data rates |
1000,2500 Mbit/s |
| Frequency band |
2.4 - 5 GHz |
| VLAN support |
Yes |
| Reset button |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Features |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Maximum data transfer rate |
8600 Mbit/s |
| Ethernet LAN data rates |
1000,2500 Mbit/s |
| Frequency band |
2.4 - 5 GHz |
| VLAN support |
Yes |
| Rate limiting |
Yes |
| Quality of Service (QoS) support |
Yes |
| Networking standards |
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11n, IEEE 802.1Q, IEEE 802.3at |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Maximum data transfer rate (2.4 GHz) |
688 Mbit/s |
| Maximum data transfer rate (5 GHz) |
8600 Mbit/s |
| Throughput data rate |
5765 Mbit/s |
| Spatial streams |
6 |
| Security |
|---|
| Security algorithms |
PPSK, WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power consumption (max) |
21 W |
| Power over Ethernet (PoE) |
Yes |
| DC voltage range |
44 - 57 V |
| Design |
|---|
| Placement |
Ceiling, Pole, Wall |
| International Protection (IP) code |
IP67 |
| Housing material |
Aluminium, Polycarbonate (PC) |
| Reset button |
Yes |
| LED indicators |
Yes |
| Product colour |
White |
| Antenna |
|---|
| Number of connectors |
2 |
| Antenna type |
Internal & external |
| Antennas quantity |
3 |
| Antenna gain level (max) |
11 dBi |
| Antenna connector type |
RP-SMA |
| Antenna direction type |
Omni-directional |
| Antenna features |
Detachable antenna |
| Technical details |
|---|
| Compliance certificates |
CE |
| Certificates |
|---|
| Compliance certificates |
CE |
| Weight & dimensions |
|---|
| Width |
170 mm |
| Depth |
66.5 mm |
| Height |
208 mm |
| Weight |
1.2 kg |
| Packaging data |
|---|
| Mounting kit |
Yes |
| Packaging content |
|---|
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Operational conditions |
|---|
| Operating relative humidity (H-H) |
5 - 95% |
| Operating temperature (T-T) |
-30 - 60 °C |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
