RJ45, 200mV p-p, 15W, 500mA, 86 x 46 x 33 mm
Key Features
- Delivers up to 15W of PoE
- Surge, peak pulse, and overcurrent protection
- Contains RJ45 data input, AC cable with earth ground, and PoE output
- LED indicator for status monitoring
Description
An adapter that can power UniFi PoE devices, reduce dependency on PoE switch power, and provide a Gigabit LAN connection.
Specifications
| Network |
|---|
| Power over Ethernet (PoE) |
Yes |
| Ethernet interface type |
Gigabit Ethernet |
| Power over Ethernet (PoE) type supported |
Active PoE |
| Power over Ethernet (PoE) voltage |
48 V |
| Features |
|---|
| Easy to install |
Yes |
| Surge protection |
Yes |
| Product colour |
White |
| LED indicators |
Status |
| Ports & interfaces |
|---|
| RJ-45 input ports |
2 |
| Power |
|---|
| Output power |
15 W |
| Power over Ethernet (PoE) voltage |
48 V |
| Input current |
0.5 A |
| AC adapter input voltage |
100 - 240 V |
| AC adapter frequency |
50/60 Hz |
| Inrush current |
100 A |
| Efficiency |
84.25% |
| Switching frequency |
65 kHz |
| Line regulation |
3% |
| Load regulation |
5% |
| Response time |
1 ns |
| Certificates |
|---|
| Compliance certificates |
CE, UL |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-30 - 70 °C |
| Operating temperature (T-T) |
0 - 40 °C |
| Operating temperature (T-T) |
-30 - 70 °F |
| Operating relative humidity (H-H) |
10 - 95% |
| Weight & dimensions |
|---|
| Weight |
100 g |
| Width |
86 mm |
| Depth |
46 mm |
| Height |
33 mm |
| Technical details |
|---|
| Power over Ethernet (PoE) |
Yes |
| Operating temperature (T-T) |
-30 - 70 °F |
| Input current |
0.5 A |
| Ethernet interface type |
Gigabit Ethernet |
| Compliance certificates |
CE, UL |
| Indication |
|---|
| LED indicators |
Status |
