Ubiquiti LTU Instant 5 White Power over Ethernet (PoE)
SAVE 66%

Ubiquiti

Ubiquiti LTU Instant 5 White Power over Ethernet (PoE)

Read reviews
SKU: LTU-INSTANT-5
Your price $287.38
List price $856.90 Save $569.52
GST included · AUD
New Sealed in box Australian stock Warehouses in Sydney, Melbourne, Brisbane, Adelaide and Perth Delivery only - Pickup unavailable 2-5 Business days metro delivery. Australian manufacturer Warranty

In stock — ready to ship

Estimate shipping

Enter an Australian postcode for a quick estimate.

Final shipping options and price are confirmed at checkout.

  • Local Australian stock
  • Australian manufacturer warranty
  • GST included
  • Secure checkout

Need bulk pricing for schools or councils? Request a quote via Contact Us.

LTU, 5.15 - 5.95 GHz, 22 dBm, 550 Mbps, 8.5 W, airOS

Key Features

  • Proprietary Ubiquiti LTU core processor
  • 22 dBi high-gain antenna with InnerFeed technology
  • Easily integrates with LBE 5AC Gen 2 deployments
  • Channel width flexibility (10/20/30/40/50/60/80/100 MHz* bandwidth)
  • Configuration management from the AP side
  • Router mode support
  • Frequency splitting
  • Quick, Bluetooth-powered setup via the UISP Mobile app
  • Includes (5) feeds and (5) PoE adapters

Description

5 GHz LTU client that functions in a point-to-multipoint (PtMP) environment with the LTU Rocket as its base station.
The LTU Instant is a 5 GHz LTU client that serves as a plug-and-play conversion module for existing LiteBeam (LBE 5AC Gen 2) deployments. Designed to function in a PtMP environment with an LTU Rocket serving as its base station, the LTU Instant delivers up to 900+ Mbps* of real TCP/IP throughput with its 22 dBi high-gain antenna. It also offers a robust feature set including frequency splitting, router mode support, accommodating bandwidth options, and configuration management from the AP side. The LTU Instant can be set up in minutes and fully managed with the UISP® web application or mobile app.

Specifications

Performance
2.4 GHz No
5 GHz Yes
Frequency band 5.15 - 5.95 GHz
Web-based management Yes
Channel bandwidth 100 MHz
Certification IC
Operating system installed AirOS
Built-in processor Yes
Features
6 GHz No
2.4 GHz No
5 GHz Yes
Frequency band 5.15 - 5.95 GHz
Channel bandwidth 100 MHz
Bluetooth Yes
Throughput data rate 550 Mbit/s
Uplink/downlink ratio 25/75, 33/67, 50/50
Isolation 20 dB
Operating system installed AirOS
Built-in processor Yes
Security
Security algorithms WPA2-PSK
Management features
Web-based management Yes
Ports & interfaces
USB 2.0 ports quantity 0
Ethernet LAN (RJ-45) ports 1
Power
Power consumption (max) 8.5 W
Power over Ethernet (PoE) Yes
Power over Ethernet (PoE) type supported Passive PoE
DC voltage range 22 - 26 V
Design
International Protection (IP) code IPX6
Housing material Polycarbonate (PC)
LED indicators Network, Power
Product colour White
Certification IC
Antenna
Antenna gain level (max) 22 dBi
Antenna connector type RF
Technical details
Sustainability compliance Yes
Compliance certificates CE, Federal Communications Commission (FCC)
Certificates
Certification IC
Compliance certificates CE, Federal Communications Commission (FCC)
Weight & dimensions
Width 64.2 mm
Depth 201.5 mm
Height 56.1 mm
Weight 215 g
Antenna width 35.8 cm
Antenna weight 890 g
Antenna height 28.9 cm
Antenna depth 27.2 cm
Packaging data
Quick start guide Yes
PoE adapter included Yes
Packaging content
Quick start guide Yes
PoE adapter included Yes
Quantity per pack 5 pc(s)
Antenna included Yes
Operational conditions
Operating temperature (T-T) -40 - 60 °C
Storage relative humidity (H-H) 5 - 95%
Sustainability
Sustainability compliance Yes
Logistics data
Quantity per pack 5 pc(s)
Brand
Ubiquiti
SKU
LTU-INSTANT-5
