574 Mbps (2.4 GHz) + 2402 Mbps (5 GHz), 802.3at PoE, 1x Gigabit Ethernet, IP68, 207.5 x 58 x 230 mm
Key Features
- Superior WiFi 6 Speeds: 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz
- Directional Ultra-Range Coverage: Equipped with built-in high-gain directional antennas to deliver precise and extended coverage
- Ideal for Warehouses and Outdoor Scenes: Features an IP68 waterproof enclosure with -30°C to +70°C operating range
- 802.11k/v/r Seamless Roaming: Ensures uninterrupted connectivity for AGVs and handheld scanners
- Flexible Deployment: Supports 802.3at PoE and Omada Mesh technology
- Centralized Cloud Management: Control everything from a single interface anywhere via the Omada app or Web UI
Description
TP-Link EAP650 D30-Outdoor AX3000 Indoor/Outdoor Wi-Fi 6 Access Point
• Superior Wi-Fi 6 Speeds: 2402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz.†
• Directional Ultra-Range Coverage: Equipped with built-in high-gain directional antennas to deliver precise and extended coverage.*
• Ideal for Warehouses and Outdoor Scenes: Features an IP68 waterproof enclosure with -30°C to +70°C operating range.
• 802.11k/v/r Seamless Roaming: Ensures uninterrupted connectivity for AGVs and handheld scanners.§
• Flexible Deployment: Supports 802.3at PoE and Omada Mesh technology.
• Centralised Cloud Management: Control everything from a single interface anywhere via the Omada app or Web UI.§
Warranty Period: 3-Year
Specifications
| Performance |
|---|
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Automatic channel selection |
Yes |
| Maximum data transfer rate |
3000 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Web-based management |
Yes |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.3at |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Band steering |
Yes |
| Airtime Fairness (ATF) |
Yes |
| Remote Authentication Dial-In User Service (RADIUS) |
Yes |
| Features |
|---|
| 6 GHz |
No |
| 2.4 GHz |
Yes |
| 5 GHz |
Yes |
| Automatic channel selection |
Yes |
| Maximum data transfer rate |
3000 Mbit/s |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Networking standards |
IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.11v, IEEE 802.3at |
| Bluetooth |
Yes |
| MIMO type |
Multi User MIMO |
| MIMO |
Yes |
| Band steering |
Yes |
| Airtime Fairness (ATF) |
Yes |
| Maximum data transfer rate (2.4 GHz) |
574 Mbit/s |
| Maximum data transfer rate (5 GHz) |
2402 Mbit/s |
| Security |
|---|
| Security algorithms |
SNMP, SNMPv2, SNMPv3 |
| MAC address filtering |
Yes |
| Remote Authentication Dial-In User Service (RADIUS) |
Yes |
| Management features |
|---|
| Web-based management |
Yes |
| Ports & interfaces |
|---|
| Ethernet LAN (RJ-45) ports |
1 |
| Power |
|---|
| Power over Ethernet (PoE) |
Yes |
| AC input voltage |
48 V |
| Power over Ethernet (PoE) type supported |
Passive PoE |
| Design |
|---|
| Placement |
Ceiling, Wall |
| Product colour |
White |
| Antenna |
|---|
| Antenna type |
Internal |
| Weight & dimensions |
|---|
| Width |
207.5 mm |
| Depth |
58 mm |
| Height |
230 mm |
| Packaging data |
|---|
| Quick start guide |
Yes |
| Mounting kit |
Yes |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Mounting kit |
Yes |
| Quantity per pack |
1 pc(s) |
| Other features |
|---|
| Vertical beam width |
30° |
| Horizontal beam width |
30° |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
