Wi-Fi 7, 6 GHz, 5 GHz and 2.4 GHz, 1×10 Gbps WAN, 4×2.5 Gbps LAN, 76 × 231.7 × 203 mm
Description
Blazing-Fast 9.7 Gbps Tri-Band Wi-Fi: Wi-Fi 7 unleashes the full potential of the 6 GHz band with up to 320 MHz channels and 9.7 Gbps Wi-Fi speeds. Enjoy full access to 8K streaming and high-speed downloading.
Faster than Wi-Fi 6E: Multi-Link Operation (MLO) enables Archer BE550 Pro to transmit data with Wi-Fi 7 clients across the 6 GHz, 5 GHz and 2.4 GHz bands simultaneously, delivering faster Wi-Fi speeds than Wi-Fi 6/6E routers.
4× Lower Latency with Minimal Buffering: Significantly lower latency than Wi-Fi 6/6E routers enables emerging applications like VR/AR, video conferencing, and online gaming to always run at top performance.
Higher Capacity for More Devices: Communicates with multiple devices and tri-band simultaneously. Combined with the powerful CPU, Wi-Fi 7 provides congestion-free signals to your laptop, TV, thermostat, and baby monitor.
EasyMesh-Compatible: Works with EasyMesh routers and range extenders to form seamless whole home Mesh WiFi, preventing drops and lag when moving between signals.
TP-Link HomeShield: Enhanced security defends against the latest cyber threats.
Specifications
| Ethernet LAN features |
|---|
| Ethernet WAN |
Yes |
| Ethernet LAN interface type |
2.5 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| DSL features |
|---|
| DSL WAN |
No |
| Mobile network |
|---|
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| Protocols |
|---|
| DMZ support |
Yes |
| Universal Plug and Play (UPnP) |
Yes |
| DHCP server |
Yes |
| DHCP client |
Yes |
| Management features |
|---|
| Universal Plug and Play (UPnP) |
Yes |
| WPS push button |
Yes |
| Reset button |
Yes |
| Packaging content |
|---|
| Package type |
Box |
| Number of products included |
1 pc(s) |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| Antenna included |
Yes |
| WAN connection |
|---|
| Ethernet WAN |
Yes |
| DSL WAN |
No |
| SIM card slot |
No |
| 3G/4G USB modem compatibility |
No |
| WAN connection type |
RJ-45 |
| Wireless LAN features |
|---|
| Top Wi-Fi standard |
Wi-Fi 7 (802.11be) |
| WLAN data transfer rate (max) |
9700 Mbit/s |
| Wi-Fi band |
Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), Wi-Fi 7 (802.11be) |
| Network |
|---|
| Ethernet LAN interface type |
2.5 Gigabit Ethernet |
| Ethernet LAN |
Yes |
| Port forwarding |
Yes |
| Ethernet LAN data rates |
10,100,1000,2500 Mbit/s |
| Port triggering |
Yes |
| Number of guest networks (5 GHz) |
1 |
| Number of guest networks (2.4 GHz) |
1 |
| Built-in FTP server |
Yes |
| VPN server |
OpenVPN Server, PPTP VPN Server, L2TP VPN Server, WireGuard VPN Server |
| Dynamic DNS (DDNS) |
Yes |
| Number of guest networks (6 GHz) |
1 |
| Ports & interfaces |
|---|
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
5 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
1 |
| Security |
|---|
| DMZ support |
Yes |
| Parental control |
Yes |
| Design |
|---|
| Product type |
Tabletop router |
| On/off switch |
Yes |
| LED indicators |
LAN, WAN |
| Product colour |
Black |
| Certificates |
|---|
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Antenna |
|---|
| Antenna design |
Internal |
| Antennas quantity |
6 |
| Power |
|---|
| Power source type |
DC |
| Output voltage |
12 V |
| Output current |
3.3 A |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
76 mm |
| Height |
203 mm |
| Depth |
231.7 mm |
| Packaging data |
|---|
| Package type |
Box |
| Cables included |
LAN (RJ-45) |
| AC adapter included |
Yes |
| Quick installation guide |
Yes |
| Number of products included |
1 pc(s) |
| Antenna included |
Yes |
| Technical details |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, Federal Communications Commission (FCC), RoHS |
