4K UHD @ 60 Hz, USB Type-C, USB, Ethernet, 3.5 mm, DisplayPort
Key Features
- Supports single and dual 4K UHD @ 60 Hz video via two DisplayPort™ 1.2a ports or HDMI 2.0 ports
- Power Delivery 3.0 up to 100W for USB-C hosts
- 1 USB 3.2 Gen 2 Type-C (10 Gbps) port
- 4 USB 3.2 Gen 1 Type-A ports (1 fast charging)
- 1 Gigabit Ethernet port
- 1 3.5mm combo Audio In/Out port
- Integrated lock slot accommodates standard security locks to safeguard equipment
- 1M USB-C detachable host cable (C/M to C/M) with (C/F to A/M) tethered adapter
- Compatible with Targus VESA® Mounting Bracket (ACX003GLZ, sold separately)
Description
Expand your workstation and connect to virtually any laptop with the Universal USB-C® DV4K Docking Station with 100W Power. Designed to support and power a wide variety of USB-C laptops and operating systems, including Windows®, macOS®, Android™, ChromeOS™, and Ubuntu®, this patented dock packs all of the ports and power you need.
Enjoy sharp 4K video while supporting a connection up to two monitors with its two HDMI and two DisplayPort™ connections. Plus connect all your favorite accessories – like a mouse, keyboard, hard drive, and more – with a combination of USB-A (4x USB 3.2 Gen 1 Type-A ports) and USB-C (1x 3.2 Gen 2 Type-C), plus Ethernet and audio ports.
Designed for the modern workstation, the dock comes equipped with a VESA® bracket mounting provision, which allows for use of the Targus VESA Mount Bracket (ACX003GLZ – sold separately) to hold your dock behind your display for even greater space savings.
Supports Dual DisplayPort™ and HDMI MonitorsThe USB-C® Universal DV4K Docking Station with 100W Power is Thunderbolt™ 3 compatible, but that’s only the beginning. Enjoy two DisplayPort™ or two HDMI ports (or a mix of the two) with your dual display and create a picture-perfect image at 4K Ultra HD. Compare photos, documents, spreadsheets for work, or browse email with ease from screen to screen. Enjoy unbeatable compatibility all in one place using a single docking station with power.
All About the PortsWith one USB 3.2 Gen 2 Type-C port and four USB 3.2 Gen 1 Type-A ports, it’s simple to connect the latest keyboards, exterior drives, and other peripherals to customize your workspace experience. The dock also includes a fast-charging port for charging your smartphone, tablet, or other devices.
Innovative DesignCompact and sleek, this patented dock is a sure fit for shrinking desktops and tight spaces. The dock is also equipped with a VESA® bracket mounting provision, which allows for use of the Targus VESA Mount Bracket (ACX003GLZ – sold separately) to hold your dock behind your display for even greater space savings.
Specifications
| Ports & interfaces |
|---|
| Combo headphone/mic port |
Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
1 |
| Connectivity technology |
Wired |
| Host interface |
USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| Ethernet LAN (RJ-45) ports |
1 |
| HDMI ports quantity |
2 |
| HDMI version |
1.4b |
| DisplayPorts quantity |
2 |
| Microphone in |
Yes |
| Headphone outputs |
1 |
| Headphone connectivity |
3.5 mm |
| DC-in jack |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery revision |
3.0 |
| USB Power Delivery up to |
100 W |
| DisplayPort version |
1.2a |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100,1000 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Product colour |
Black |
| Country of origin |
Thailand |
| Card reader integrated |
No |
| Cable lock slot |
Yes |
| Certification |
CE, FCC, RoHS |
| Cable lock slot type |
Kensington |
| HD type |
4K Ultra HD |
| VESA mounting |
Yes |
| Maximum refresh rate |
60 Hz |
| Storage |
|---|
| Card reader integrated |
No |
| Power |
|---|
| Power source type |
DC |
| Output voltage |
19 V |
| Output current |
7.89 A |
| Power supply |
150 W |
| Software |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Linux operating systems supported |
Yes |
| Other operating systems supported |
ChromeOS |
| Mobile operating systems supported |
Android |
| Weight & dimensions |
|---|
| Width |
82.6 mm |
| Depth |
31.8 mm |
| Height |
179.3 mm |
| Weight |
340 g |
| Design |
|---|
| Windows operating systems supported |
Yes |
| Mac operating systems supported |
Yes |
| Product colour |
Black |
| Country of origin |
Thailand |
| Cable lock slot |
Yes |
| Certification |
CE, FCC, RoHS |
| Cable lock slot type |
Kensington |
| Packaging data |
|---|
| Quantity per pack |
1 pc(s) |
| Packaging content |
|---|
| Quick start guide |
Yes |
| Cables included |
AC, USB Type-A to USB Type-C |
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Compliance certificates |
RoHS |
