Synology FlashStation FS3410 NAS/storage server Rack (2U) Intel® Xeon® D D-1541 16 GB DDR4 DSM Black

Intel Xeon D-1541 8-core 2.1 GHz, 16 GB DDR4 ECC RDIMM, 24 x 2.5" SATA SSD, 2 x USB 3.2 Gen 1, 2U, 100-240V, 15 kg

Description

Economical, high-performance data management solution for SMBs

Harness all-flash storage to speed up business workflows
With 24 all-flash bays in a 2U rackmount enclosure, the Synology FlashStation FS3410 is the ideal solution for SMBs, enterprise offices, and data centers requiring high sustained I/O performance for applications such as video post-production, virtual machines (VMs), enterprise email servers, and online transaction processing.

Storage
Supports 24 x 2.5” SATA SSDs

Throughput
Over 356,500/129,400 iSCSI 4K random read/write IOPS1

Memory
16 GB DDR4 ECC RDIMM, up to 128 GB

Expandability
Optional 25/40GbE through PCIe 3.0 expansion

Powerful flash storage server
Combine all-flash performance with Synology systems’ ease of use and reliability. The FS3410 is designed to tackle scenarios that require high throughput and low latency.

Built for high reliability
The FS3410 is built to keep mission-critical data and services always accessible, enabling businesses to continue to perform even when disaster strikes.

Out-of-band (OOB) management
Simplify troubleshooting by managing powered-down devices remotely and accessing critical logs through a dedicated interface.

Dual power supply
Redundant PSU units reduce the possibility of power disruptions on a single distribution channel or PDU adversely impacting data and service availability.

Failover cluster
Pair two FS3410 units with Synology High Availability to enable automatic minute-level failover in the event of server failure or to minimize downtime when performing system updates or upgrades.

Powerful networking options
The FS3410 supports a wide range of networking interfaces, protocols, and configurations, whether you need fast sequential transfer, support for simultaneous connections, or high network redundancy.

Built-in fast connectivity
Two 10GbE RJ-45 ports and four Gigabit Ethernet ports allow for rapid transfer speeds right out of the box.

Support for 10/25/40GbE
Add up to 2 x 10/25/40GbE network interface cards using the 2 x PCIe 3.0 slots to enable lightning fast networking in minutes.

Failover and network balancing
Bond multiple network interfaces with Link Aggregation to enable automatic network failover and load balancing.

Versatile data storage
The FS3410 fits perfectly in file server, block storage, or light application server roles that require high availability, reliability, and leading-edge storage technology.

Specifications

Storage
Storage drives installed	No
Installed storage drive type	No
Supported storage drive types	SSD
Number of storage drives supported	24
RAID support	Yes
RAID levels	0, 1, 5, 6, 10, F1, JBOD
Hot-swap drive bays	Yes
Supported file systems	BTRFS, FAT32, HFS+, NTFS, exFAT, ext3, ext4
Supported storage drive interfaces	Serial ATA III
Storage drive sizes supported	2.5"
Total installed system drives capacity	1000 TB
Processor
Processor manufacturer	Intel
Processor family	Intel® Xeon® D
CPU configuration (max)	1
Processor threads	16
Processor cache	12 MB
Processor boost frequency	2.7 GHz
Conflict-Free processor	Yes
Processor model	D-1541
Processor frequency	2.1 GHz
Processor cores	8
Memory
Internal memory type	DDR4
Internal memory	16 GB
Maximum RAM supported	128 GB
Memory form factor	RDIMM
ECC	Yes
Network
Ethernet LAN data rate supported (max)	10000 Mbit/s
Ethernet LAN	Yes
Ethernet LAN data rates	10,100,1000,10000 Mbit/s
iSCSI support	Yes
Wake-on-LAN ready	Yes
Supported network protocols	SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
Ports & interfaces
USB port	Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
Ethernet LAN (RJ-45) ports	7
PCI Express x8 (Gen 3.x) slots	2
Serial ports quantity	1
Design
Chassis type	Rack (2U)
Product colour	Black
Cooling type	Active
Number of fans	4 fan(s)
LED indicators	Status
Performance
System log	Yes
Share folder	Yes
Browser supported	Google Chrome, Firefox, Microsoft Edge, Safari 13
Type	Storage server
Device class	Large Enterprise Business
Backup function	Yes
Backup features	Cloud, USB drive
Multilingual support	Yes
Number of users	16000 user(s)
Operating system installed	DSM
Operating system version	7.1
Security algorithms	AES
Access Control List (ACL)	Yes
Snapshot	Yes
Software
Operating system installed	DSM
Operating system version	7.1
Power
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Weight & dimensions
Width	430.5 mm
Depth	692 mm
Height	88 mm
Weight	15 kg
Technical details
Sustainability compliance	Yes
Compliance certificates	CE, RoHS
Packaging content
Quick start guide	Yes
Cables included	AC
Power cables quantity	2
Processor special features
Intel VT-x with Extended Page Tables (EPT)	Yes
Intel Virtualization Technology for Directed I/O (VT-d)	Yes
Intel Virtualization Technology (VT-x)	Yes
Intel TSX-NI version	1.00
Intel TSX-NI	Yes
Intel Trusted Execution Technology	Yes
Intel Secure Key Technology version	1.00
Intel Enhanced Halt State	Yes
Intel 64	Yes
Idle States	Yes
Execute Disable Bit	Yes
Enhanced Intel SpeedStep Technology	Yes
Embedded options available	No
Sustainability
Sustainability compliance	Yes
Operational conditions
Operating temperature (T-T)	0 - 35 °C
Operating relative humidity (H-H)	8 - 80%
Storage temperature (T-T)	-20 - 60 °C
Storage relative humidity (H-H)	5 - 95%
Other features
Compliance certificates	CE, RoHS
