StarTech SPDIF Digital Coaxial or Toslink Optical to Stereo RCA Audio Converter - Digital Audio Adapter (SPDIF2AA)
Key Features
- Accepts Digital Coax or Toslink digital audio input
- Outputs analog L/R RCA stereo analog audio
- Compact form factor
- Easy to install and use
- 24-bit S/PDIF incoming bit stream
- Supports 32, 44.1, 48 and 96 KHz sampling rates
Description
Convert a Digital Coax or Toslink Signal to Stereo RCA Audio
The SPDIF2AA Toslink/Optical SPDIF to RCA Audio Converter lets you convert a 2-channel Digital Coaxial or Toslink/Optical SPDIF input signal into an RCA analog stereo output.
Perfect for home and professional audio applications, this SPDIF to RCA audio converter saves the cost of upgrading equipment for compatible connections, and offers separate Digital Coax and Toslink inputs for dual-function conversion. The small form factor design makes it suitable for installation into virtually any location, regardless of space constraints, while still providing a lossless audio signal. Plus, the digital coaxial or Toslink to RCA converter supports plug-and-play installation, saving you time and hassle.
Backed by a StarTech.com 2-year warranty and free lifetime technical support.
Specifications
| Inputs |
|---|
| USB 1.1 ports quantity |
0 |
| Sample frequencies |
32, 44.1, 48, 96 KHz |
| Digital audio optical in |
1 |
| Digital audio coaxial in |
1 |
| Outputs |
|---|
| Audio (L/R) out |
1 |
| Technical details |
|---|
| Product colour |
Black |
| Certification |
CE, FCC |
| Housing material |
Steel |
| Harmonized System (HS) code |
85176990 |
| Power |
|---|
| Power consumption (typical) |
0.5 W |
| Operating voltage |
5 V |
| External power adapter |
Yes |
| Input voltage |
100 - 240 V |
| Weight & dimensions |
|---|
| Width |
42 mm |
| Depth |
52 mm |
| Height |
27 mm |
| Weight |
72 g |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 70 °C |
| Storage temperature (T-T) |
-10 - 80 °C |
| Operating relative humidity (H-H) |
10 - 85% |
| Packaging data |
|---|
| Package width |
175 mm |
| Package depth |
144 mm |
| Package height |
41 mm |
| Package weight |
368 g |
| Quantity |
1 |
| Logistics data |
|---|
| Master (outer) case width |
405 mm |
| Master (outer) case length |
360 mm |
| Master (outer) case height |
320 mm |
| Products per master (outer) case |
36 pc(s) |
| Harmonized System (HS) code |
85176990 |
