StarTech.com Multi-Mode (MM) ST Fiber Media Converter for 10/100Mbps Networks, Standalone Ethernet to ST MM Fiber Media Converter, 1310nm, 2km - TAA

StarTech Multi-Mode (MM) ST Fiber Media Converter for 10/100Mbps Networks, Standalone Ethernet to ST MM Fiber Media Converter, 1310nm, 2km - TAA

Key Features

• Enable Long-Range Network Connectivity: Convert 10/100 Mbps Ethernet to multi-mode ST fiber and extend up to 1.2mi (2km), delivering secure, interference-resistant links for edge, industrial, and remote sites where copper falls short
• Deploy Anywhere with Minimal Setup: Compact media converter installs in tight spaces, enabling fast integration into data centers or server rooms; TAA compliant for procurement standards; Does not work with MCM7-MEDIA-CHASSIS or MCM15-MEDIA-CHASSIS
• Configurable DIP Switches: Plug-and-play media converter auto-negotiates across networks or uses DIP switches to force speed, duplex, and link-fault passthrough settings, reducing mismatches, isolating faults, and accelerating deployments
• Deploy Efficiently in Compact, Power-Sensitive Spaces: Operates at just 2.4W with 12V DC input via included power adapter or an optional chassis power supply, supporting 32°F to 122°F (0°C to 50°C) environments; Does not support PoE
• The IT Pro's Choice: Designed for reliability in edge and on-prem deployments, our media converters are lab-tested and field-proven for seamless integration and maximum uptime; Backed by free lifetime 24/5 multi-lingual technical assistance

Description

Convert and extend a 10/100 Mbps Ethernet connection up to 2 km over Multi Mode ST fiber

The MCM110ST2 10/100 Multi Mode ST Fiber Ethernet Media Converter (2 km) creates a cost-effective Ethernet to fiber link, transparently converting to/from 10Base-T or 100Base-Tx Ethernet signals and 100Base-Fx optical signals to extend an Ethernet network connection over a multimode fiber backbone.
The ST media converter supports a maximum multimode fiber optic cable distance of 2km (1.2 miles), providing a simple solution for connecting 10Base-T/100Base-Tx Ethernet networks to remote locations using ST-terminated multimode fiber, while delivering solid network performance and scalability.
Easy to setup and install, this compact, value-conscious fast Ethernet media converter features auto-switching MDI and MDI-X support on the RJ45 UTP connections as well as manual controls for UTP mode, speed, Full and Half Duplex, as well as LFP (Link Fault pass-through) on/off.

Specifications

Network
Data transfer rate	100 Mbit/s
Maximum data transfer rate	100 Mbit/s
Converter input interface	10Base-T, 100BASE-FX, 100Base-TX
Networking standards	IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10,100 Mbit/s
Duplex system	Full, Half
Fiber optic connector	ST
Performance
Wavelength-division multiplexing (WDM)	No
Wavelength	1310 nm
Maximum transfer distance	2000 m
Sensitivity	-31 dBmW
Link budget	11 dB
Mean time between failures (MTBF)	65000 h
Features
Internal	No
LED indicators	Yes
Housing material	Plastic
Ports & interfaces
Connectivity technology	Wired
Ethernet LAN (RJ-45) ports	1
Fiber optic connector	ST
Power
Power plug type	Type M
Input voltage	100 - 240 V
Output voltage	12 V
Output current	0.2 A
Power consumption (typical)	2.4 W
Power over Ethernet (PoE)	No
Weight & dimensions
Width	75 mm
Depth	95 mm
Height	20 mm
Weight	82 g
Package width	145 mm
Package depth	175 mm
Package height	61 mm
Package weight	273 g
Operational conditions
Operating temperature (T-T)	0 - 50 °C
Storage temperature (T-T)	-10 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Packaging content
AC adapter included	Yes
Manual	Yes
Packaging data
Package width	145 mm
Package depth	175 mm
Package height	61 mm
Package weight	273 g
Design
Internal	No
LED indicators	Yes
Housing material	Plastic
Certification	CE, FCC, TAA, REACH
Technical details
Data transfer rate	100 Mbit/s
Compliance certificates	RoHS
Certificates
Certification	CE, FCC, TAA, REACH
Compliance certificates	RoHS
Other features
Link budget	11 dB
