StarTech 2 Port High Resolution VGA Video Splitter with Built-in Amplifier, 350 MHz, VGA Splitter 1 x 2, 2048x1536 80Hz - TAA Compliant
Key Features
- Allows 1 VGA video source to simultaneously duplicate to 2 different monitors
- Supports resolutions up to 2048x1536 @ 80Hz; High video bandwidth (350 MHz)
- Daisy chainable to mirrored output for almost unlimited expansion
- Built-in video amplifier boosts the signal to allow a cable length of up to 210 ft or 65m
- Uses standard monitor extension cables; DDC compatible; Includes AC 120V power adapter
Description
Split a single high resolution VGA video signal to 2 monitors or projectors
The ST122PRO 2 Port High Resolution VGA Video Splitter - 350 MHz splits a VGA video source signal to 2 monitors or projectors simultaneously - a professional grade solution that is perfect for presentations, classrooms, tradeshows, or in-store displays, where the highest-quality identical video output on several monitors is needed. This High Resolution VGA Splitter supports monitors with up to 350MHz of video bandwidth and display resolutions up to 2048x1536 @80Hz. For added versatility, the VGA splitter features an integrated booster circuit that allows the video signal to be extended up to 210 feet (65 meters), enabling you to situate your displays in the most convenient location based on your application. This product is TAA compliant. Male to Female VGA extension cable required (MXT101HQ)
Specifications
| Ports & interfaces |
|---|
| Video ports quantity |
2 |
| Video port type |
VGA |
| Video out |
2x VGA |
| Features |
|---|
| Maximum refresh rate |
80 Hz |
| Maximum resolution |
2048 x 1536 pixels |
| Maximum operating distance |
65 m |
| Product colour |
Black |
| Certification |
CE, FCC, TAA, REACH |
| Bandwidth |
350 MHz |
| Power |
|---|
| Input current |
0.6 A |
| Output current |
0.6 A |
| Power consumption (typical) |
3 W |
| Output voltage |
5 V |
| Weight & dimensions |
|---|
| Weight |
366 g |
| Width |
80 mm |
| Depth |
180 mm |
| Height |
21 mm |
| Package weight |
670 g |
| Package depth |
187 mm |
| Package width |
240 mm |
| Package height |
97 mm |
| Packaging data |
|---|
| Package weight |
670 g |
| Package depth |
187 mm |
| Package width |
240 mm |
| Package height |
97 mm |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Manual |
Yes |
| Video |
|---|
| Maximum refresh rate |
80 Hz |
| Maximum resolution |
2048 x 1536 pixels |
| Bandwidth |
350 MHz |
| Colour |
|---|
| Product colour |
Black |
| Certificates |
|---|
| Certification |
CE, FCC, TAA, REACH |
| Technical details |
|---|
| Video out |
2x VGA |
| Package width |
240 mm |
| Package height |
97 mm |
| Maximum operating distance |
65 m |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Master (outer) case width |
524 mm |
| Master (outer) case length |
410 mm |
| Master (outer) case height |
330 mm |
| Products per master (outer) case |
12 pc(s) |
