StarTech 10ft (3m) DisplayPort to DVI Cable - DisplayPort to DVI Adapter Cable 1080p Video - DisplayPort to DVI-D Cable Single Link - DP to DVI Monitor Cable - DP 1.2 to DVI Converter (DP2DVIMM10)
Key Features
- DISPLAYPORT TO DVI CABLE: 10ft (3m) DisplayPort 1.2 (HBR2) to DVI-D single-link cable connects a DVI display, monitor or projector supports 1920x1200 or 1080p at 60Hz; HDCP 1.3 / EDID pass-through ensures compatibility between source & display
- COMPATIBILITY: Passive video converter supports DP++ sources including workstations, desktops (AMD/Nvidia), laptops, small form factor computers & docking stations; 10' length supports longer distances than traditional DVI cable
- INTEGRATED DISPLAY CABLE: DisplayPort to DVI adapter cable has slim/flexible design w/ adapter chip built into DVI connector reducing clutter & providing a tidy install in the office, boardroom or home office
- STABLE CONNECTION: Non-latching DP connector is easy to disconnect from a hard to reach source, and chip built into DVI connector minimizes signal loss / Supports DVI screw locking cable to prevent cable from coming loose or accidental disconnection
- EASY TO USE: With no software or drivers required, the DP to DVI cable/cord works with any OS including Windows, Ubuntu and macOS; DisplayPort male to DVI male cable
Description
Connect your DVI monitor to a DisplayPort equipped computer using a single cable
The DP2DVIMM10 DisplayPort to DVI (M-M) Video Converter Cable lets you connect a DVI capable display to a DisplayPort video card/source using a single cable. The cable provides a connection distance of 10ft and features a male DVI connector and a male DisplayPort connector.
The DisplayPort/DVI video converter cable supports high bandwidth video transmissions, easily delivering monitor resolutions up to 1920x1200 or HDTV resolutions up to 1080p - allowing you to take full advantage of your DVI capable display, while using a cutting edge DisplayPort video source.
DP2DVIMM10 is a passive adapter cable that requires a DP++ port (DisplayPort++), meaning that DVI and HDMI signals can also be passed through the port.
Backed by a StarTech.com 3-year warranty and free lifetime technical support.
Specifications
| Features |
|---|
| DisplayPort version |
1.2 |
| Cable length |
3 m |
| Connector 1 |
DisplayPort |
| Connector 2 |
DVI-D |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| Connector contacts plating |
Nickel |
| Product colour |
Black |
| Jacket material |
Polyvinyl chloride (PVC) |
| Maximum resolution |
1920 x 1200 pixels |
| Supported video modes |
1080p |
| Plug and Play |
Yes |
| Certification |
CE, FCC, REACH |
| Connector 1 form factor |
Straight |
| Connector 2 form factor |
Straight |
| Dual Link DVI |
No |
| Certificates |
|---|
| Certification |
CE, FCC, REACH |
| Compliance certificates |
RoHS |
| Other features |
|---|
| Depth |
3000 mm |
| Quantity outer carton |
120 pc(s) |
| Weight & dimensions |
|---|
| Weight |
246 g |
| Package width |
346 mm |
| Package depth |
285 mm |
| Package height |
31 mm |
| Package weight |
269 g |
| Depth |
3000 mm |
| Packaging data |
|---|
| Package width |
346 mm |
| Package depth |
285 mm |
| Package height |
31 mm |
| Package weight |
269 g |
| Quantity per pack |
1 pc(s) |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Technical details |
|---|
| Harmonized System (HS) code |
84733080 |
| Compliance certificates |
RoHS |
| Logistics data |
|---|
| Master (outer) case width |
509 mm |
| Master (outer) case length |
345 mm |
| Master (outer) case height |
229 mm |
| Products per master (outer) case |
30 pc(s) |
| Harmonized System (HS) code |
84733080 |
