StarTech 3.3ft (1m) USB-C Cable, Right-Angled, USB 10Gbps, 100W (5A) PD, 8K 60Hz / 4K 144Hz, Thunderbolt Compatible
Key Features
- RIGHT ANGLE USB CABLE: Rugged USB Type-C Cable features a right angle USB-C connector; Ideal for connecting in tight spaces; 90 degree connector optimizes cable routing without placing unnecessary strain on the connector and device
- DURABLE CONSTRUCTION: The USB-C cable is reinforced with Aramid fiber to enhance flexibility and protection from frequent bending and wear; Robust strain reliefs with 8mm Bend Radius; Nickel-plated connectors rated beyond 10,000 Insertion Cycles
- FULL-FEATURE USB-C: Right angle USB-C cable supports up to 10 Gbps transfer rates, 8K 60Hz DP Alt Mode, and 100W Power Delivery; Universal compatibility between USB-C laptops, docking stations, UHD monitors, and external devices
- THOUGHTFUL DESIGN: Built-in E-Marker chip for consistent data, video, and Power Delivery output; Flexible TPE outer jacket is nontoxic, halogen-free, and RoHS compliant; Aluminum-mylar shield for enhanced EMI protection
- PERFORMANCE: USB 3.2 Gen 2 (10 Gbps); 8K 60Hz / 4K 144Hz DP Alt Mode 1.2; 100W Power Delivery; 3.3ft (1m); Black; 4.8mm O.D.; Dock and charge a USB-C laptop over a single connection; Optimize cable routing to a USB-C device
Description
Connect and charge USB Type-C devices with a rugged right-angle USB-C Cable
Connect USB 10Gbps source and peripheral devices, using this 3.3ft (1m) Rugged Right Angle USB Type-C Cable. Position the right angle USB-C connection along the device to reduce cable clutter and avoid prolonged strain from bending.
It is ideal for 10Gbps data transfer to external USB-C-enabled external storage devices, or as a single-cable connection from a USB-C dock to a laptop.
Experience 8K Video with DisplayPort 1.4 Alt Mode
The Rugged USB-C cable supports up to 8K 60Hz or 4K 144Hz video over DisplayPort 1.4 Alt Mode, and is compatible with 1080p and lower resolutions.
Enhanced Durability
Designed to withstand heavy use, the USB-C cable features an Aramid fiber core and durable TPE outer jacket. This heavy-duty construction protects against fraying or breakage and resists tangling.
Full-Featured USB-C Power and Data
This USB Type-C cable features Power Delivery (PD) 3.0 with up to 100W PD output. Power and charge a USB-C laptop, such as Apple MacBook, Lenovo ThinkPad, or Microsoft Surface with up to 100W output over USB Power Delivery 3.0. Connect the USB-C cable from a laptop to a USB-C wall charger or docking station.
Specifications
| Features |
|---|
| Connector 1 form factor |
Angled |
| Connector 2 form factor |
Straight |
| Cable shielding |
Aluminum mylar foil |
| USB version |
USB 3.2 Gen 2 (3.1 Gen 2) |
| Connector 1 |
USB C |
| Connector 2 |
USB C |
| Cable length |
1 m |
| Connector contacts plating |
Nickel/Gold |
| Product colour |
Black |
| Maximum data transfer rate |
10000 Mbit/s |
| Cable type |
Round cable |
| Connector 1 gender |
Male |
| Connector 2 gender |
Male |
| USB Power Delivery (USB PD) |
Yes |
| Cable jacket material |
Thermoplastic elastomer (TPE) |
| USB Power Delivery up to |
100 W |
| Maximum resolution |
4096 x 2160 pixels |
| Maximum refresh rate |
60 Hz |
| DisplayPort version |
1.2 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Maximum data transfer rate |
10 Gbit/s |
| Output current (max) |
5 A |
| Cable diameter |
4.8 mm |
| Quantity per pack |
1 pc(s) |
| Power |
|---|
| Output current (max) |
5 A |
| Weight & dimensions |
|---|
| Cable length |
1 m |
| Cable diameter |
4.8 mm |
| Bend radius (min) |
8 mm |
| Package width |
128 mm |
| Package depth |
129 mm |
| Package height |
14 mm |
| Package weight |
95 g |
| Packaging data |
|---|
| Package width |
128 mm |
| Package depth |
129 mm |
| Package height |
14 mm |
| Package weight |
95 g |
| Quantity per pack |
1 pc(s) |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Sustainability |
|---|
| Sustainability compliance |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Certificates |
|---|
| Compliance certificates |
CE, RoHS |
| Technical details |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
CE, RoHS |
| Logistics data |
|---|
| Products per master (outer) case |
200 pc(s) |
| Master (outer) case width |
442 mm |
| Master (outer) case length |
401 mm |
| Master (outer) case height |
301 mm |
| Other features |
|---|
| Cable type |
Round cable |
| Operating temperature (T-T) |
0 - 50 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Compliance certificates |
CE, RoHS |
