64.5", IPS, 3840 x 2160, 60 Hz, 92% of DCI, 10bit, 1200:1, 700 cd/m², 16:9, 100-240 V AC; 50/60 Hz
Key Features
- Enhanced imaging precision – when brand consistency and corporate identity are important, NEC’s SpectraView Engine provides full control over colour, gamma, and uniformity for accurate and impactful content.
- Unhindered readability – a high-haze panel reduces glare from windows and ambient light, keeping signage content and presentations clear for uninterrupted viewing in any environment
- Security assured – 802.2x support over LAN enables high-level security for corporate networks, giving peace of mind for IT teams and enterprise environments.
- Mission-critical performance – with 700 cd/m² brightness, long-life components and robust flame-resistant metal chassis, the P6 series is engineered to deliver lasting clarity and durability in challenging environments without the need for bulky housings.
- Trusted integration – full compatibility with major AV ecosystems, including Crestron XiO Cloud and NVX, Q-Sys, Cisco Webex, Matrox IPMX, and CMS solutions, ensures seamless setup and scalability.
Description
Precision performance for critical applicationsWhen reliability, security, and exceptional visual performance are mandatory, the Sharp MultiSync® P6 Series delivers with precision and resilience. Engineered for mission-critical applications and high-end signage, the P6 Series combines robust durability with advanced visual technologies to meet the most demanding commercial needs. With 700 cd/m² brightness, a high-haze panel, and SpectraViewTM Engine, it delivers outstanding image clarity and colour accuracy even in challenging lighting conditions. Despite its slim profile, the P6 Series is endorsed for use in heavy traffic spaces with a durable all-metal chassis that complies to the strictest fire safety standards.
Building on NEC’s trusted heritage, the next generation Sharp P6 Series is designed for longevity and integration flexibility. Its modular architecture supports custom computing options by Intel® SDM or Raspberry Pi, and flexible connectivity including AVoverIP for versatile deployments. Native video daisy chaining via HDMI and DisplayPort enables content to be easily cloned or expanded across multiple displays. Compatibility with leading platforms such as Crestron, Cisco Webex, and Q-Sys enhances its future-proof appeal, while 802.1x LAN support safeguards robust security against cyber threats. Purpose-designed for control rooms, passenger information, and prestige retail or corporate signage, the P6 Series delivers uncompromising performance, day after day.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display number of colours |
1.073 billion colours |
| Display diagonal |
163.8 cm (64.5") |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
700 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
8000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.375 x 0.375 mm |
| Display diagonal (metric) |
163.9 cm |
| Vertical scan range |
23 - 76 Hz |
| Panel type |
IPS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Horizontal scan range |
15 - 135 kHz |
| Display technology |
LCD |
| Native refresh rate |
60 Hz |
| Ports & interfaces |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| USB port |
Yes |
| Ethernet LAN data rates |
100 Mbit/s |
| DVI port |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| RS-232 interface |
Yes |
| Wi-Fi |
No |
| DisplayPorts quantity |
2 |
| DisplayPorts out |
1 |
| DisplayPorts in |
1 |
| HDMI input ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
1 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
65 W |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Kiosk design |
| Product colour |
Black |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
300 x 300 mm |
| Bezel width (top) |
1.1 cm |
| Bezel width (side) |
1.1 cm |
| Bezel width (bottom) |
1.39 cm |
| VESA mounting |
Yes |
| Performance |
|---|
| Purpose |
Retail |
| HDCP |
Yes |
| Web browser |
Yes |
| Wi-Fi |
No |
| Power |
|---|
| Power consumption (typical) |
160 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50 - 60 Hz |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
G |
| Energy consumption (SDR) per 1000 hours |
139 kWh |
| Energy consumption (HDR) per 1000 hours |
137 kWh |
| Computer system |
|---|
| Computer system |
Yes |
| Processor manufacturer |
Intel |
| Built-in processor |
Yes |
| Weight & dimensions |
|---|
| Display width |
1454.5 mm |
| Display depth |
59.5 mm |
| Display height |
832.4 mm |
| Display weight |
17.3 kg |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 80% |
| Technical details |
|---|
| VESA mounting |
Yes |
| USB connector type |
USB Type-A, USB Type-C |
| Panel type |
IPS |
| LED backlighting type |
Direct-LED |
| DisplayPorts out |
1 |
| DisplayPorts in |
1 |
| Sustainability certificates |
ENERGY STAR |
| Safety warning |
CE; EMC Class B; Energy Star 8; FCC Class B; REACH; RoHS; UKCA; UL/C-UL or CSA |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100 Mbit/s |
| Wi-Fi |
No |
| Other features |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Wi-Fi |
No |
| Panel type |
IPS |
| DisplayPorts out |
1 |
| DisplayPorts in |
1 |
| Display technology |
LCD |
| Bezel width (top) |
1.1 cm |
| Bezel width (side) |
1.1 cm |
| Bezel width (bottom) |
1.39 cm |
| Energy efficiency scale |
A to G |
