4U 24-bay 3.5" SATA HDD NAS, AMD Ryzen 7000 series 8C16T (boost up to 5.3 GHz), 32GB DDR5 non-ECC RAM (max. 192GB total), 2x M.2 2280 PCIe Gen5 x2 slots for SSD cache, 2x 10GBASE-T + 2x 2.5 GbE RJ45, 3 x PCIe Gen 4 expansion slots, 2 x 550W RPS
Key Features
- Immutable Storage: QuTS hero OS supports WORM, ZFS deduplication, compression, and high-volume snapshots to ensure data integrity and long-term retention.
- DDR5 RAM: Supports up to 192 GB DDR5 RAM, delivering stability and performance for memory-intensive applications and multi-VM workloads (ECC RAM is also supported).
- 3 x PCIe Gen 4 Expansion Slots: Easily scale with 25GbE adapters, GPUs, or storage expansion cards—customize hardware to match evolving performance needs.
- High-Speed 10/2.5GbE Ports: Equipped with dual 10GbE and dual 2.5GbE ports, ideal for fast multi-user file sharing, low-latency virtualization, and high-throughput media workflows.
- Petabyte-Level Scalability: Compatible with QNAP SAS and PCIe JBOD expansion units—build a flexible, high-capacity storage infrastructure for long-term growth.
- Long-term Supply: Supported until 2030 to ensure stability for enterprise IT planning and infrastructure lifecycle management.
Description
TS-h2477AXU-RPAMD Ryzen™ 7 PRO 7000 Series Processor and ZFS Data Integrity for Enterprise Storage and Virtualization
Purpose-built for high-performance environments, the TS-h2477AXU-RP features 24-bay SATA drive support and dual PCIe Gen 5 M.2 SSD slots to handle massive storage volumes and ultra-fast data access. Redundant power supplies ensure uninterrupted operation for mission-critical workloads. Powered by the AMD Ryzen™ 7 PRO 7000 series processor and the ZFS file system, it delivers enterprise-level data integrity and protection. Ideal for mid to large-sized teams running file servers, virtualization platforms, long-term data archiving, media production, and large-scale surveillance recording.
Specifications
| Storage |
|---|
| Total installed storage capacity |
0 TB |
| Storage drives installed |
No |
| Installed storage drive type |
No |
| Number of storage drives installed |
0 |
| Supported storage drive types |
HDD & SSD |
| Number of storage drives supported |
24 |
| Online RAID migration |
Yes |
| Online RAID expansion |
Yes |
| Disk roaming |
Yes |
| Bad block scan |
Yes |
| Storage drive capacity |
0 GB |
| RAID support |
Yes |
| RAID levels |
0, 1, 5, 6, 10, 50, 60, JBOD |
| Hot-swap drive bays |
Yes |
| Supported file systems |
FAT32, HFS+, NTFS, exFAT, ext2, ext3, ext4 |
| Supported storage drive interfaces |
M.2, Serial ATA II, Serial ATA III |
| Storage drive sizes supported |
2.5,3.5" |
| Number of M.2 (M & B) slots |
2 |
| RAID rebuild |
Yes |
| Number of system drives supported |
2 |
| Processor |
|---|
| Processor generation |
AMD Ryzen PRO 7000 Series |
| Processor manufacturer |
AMD |
| Processor family |
AMD Ryzen™ 7 |
| Processor threads |
16 |
| Processor boost frequency |
5.3 GHz |
| On-board graphics card model |
AMD Radeon Graphics |
| Processor model |
7745 |
| Processor cores |
8 |
| Number of processors supported |
1 |
| Memory |
|---|
| Internal memory type |
DDR5 |
| Internal memory |
32 GB |
| Maximum RAM supported |
192 GB |
| Memory slots |
4 |
| Flash memory |
5000 MB |
| Memory form factor |
UDIMM |
| ECC |
No |
| Network |
|---|
| Ethernet LAN data rate supported (max) |
10000 Mbit/s |
| Ethernet LAN |
Yes |
| Dynamic DNS (DDNS) |
Yes |
| Ethernet LAN data rates |
10,100,1000,2500,10000 Mbit/s |
| DHCP server |
Yes |
| iSCSI support |
Yes |
| Supported network protocols |
IPv4, IPv6 |
| Ports & interfaces |
|---|
| USB port |
Yes |
| Ethernet LAN (RJ-45) ports |
4 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity |
2 |
| Graphics |
|---|
| On-board graphics card model |
AMD Radeon Graphics |
| Design |
|---|
| Chassis type |
Rack (4U) |
| Product colour |
Black, Grey |
| Cooling type |
Active |
| Number of fans |
3 fan(s) |
| Fan diameter |
6 cm |
| LED indicators |
Power, Status |
| Performance |
|---|
| Built-in FTP server |
Yes |
| System log |
Yes |
| Share folder |
Yes |
| S.M.A.R.T. support |
Yes |
| Password authentication |
Yes |
| Disk scan |
Yes |
| Type |
Storage server |
| Device class |
Small & Medium Business |
| Backup function |
Yes |
| Backup features |
Cloud, USB drive, iSCSI LUN |
| Buzzer |
Yes |
| Multilingual support |
Yes |
| Number of users |
4096 user(s) |
| Operating system installed |
QNAP QTS |
| Operating system version |
5.2.6 |
| Web-based management |
Yes |
| Reset button |
Yes |
| On/off switch |
Yes |
| Remote administration |
PPTP, L2TP/IPSec, OpenVPN, WireGuard, QBelt |
| Software |
|---|
| Operating system installed |
QNAP QTS |
| Operating system version |
5.2.6 |
| Power |
|---|
| Power supply location |
Built-in |
| Power supply unit (PSU) capacity |
550 W |
| Number of power supply units |
2 |
| Redundant power supply (RPS) support |
Yes |
| AC input voltage |
100 - 240 V |
| Weight & dimensions |
|---|
| Width |
432.4 mm |
| Depth |
511.7 mm |
| Height |
177.3 mm |
| Package width |
600 mm |
| Package depth |
940 mm |
| Package height |
420 mm |
| Package weight |
27.7 kg |
| Technical details |
|---|
| Warranty period |
5 year(s) |
| Packaging content |
|---|
| Number of screws |
168 |
| Package type |
Box |
| Cables included |
AC, LAN (RJ-45) |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
5 - 95% |
| Storage temperature (T-T) |
-20 - 70 °C |
| Other features |
|---|
| Warranty period |
5 year(s) |
