Line Interactive, 1000VA, 600W, 8 Outlets, USB
Key Features
- Automatic Voltage Regulation (Buck and Boost)
- Informative Screen Display
- USB Charging Port
- Light-weight compact and elegantly designed
- Intelligent microprocessor control
- Monitoring and shutdown software included
- Overload protection and alarm
- Output short circuit protection
- Start on battery function (cold start)
- USB communication
- Easy user-replaceable battery
- Australian/New Zealand approved sockets
- Wall mountable
Description
The SafeGuard UPS 1000 provides a buffer between your equipment and inconsistent mains power supply. This cost effective, compact device constantly stands guard beside your sensitive equipment. The informative display and USB charging port are unique to this model and offer a complete solution for protecting valuable equipment.
Specifications
| Power |
|---|
| Output power capacity |
1 kVA |
| Output power |
600 W |
| Input operation voltage (min) |
177 V |
| Input operation voltage (max) |
290 V |
| Surge energy rating |
475 J |
| Power factor |
0.6 |
| Output voltage regulation |
10% |
| Performance |
|---|
| UPS topology |
Line-Interactive |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Response time |
6 ms |
| Waveform |
Pseudo sine |
| Noise level |
40 dB |
| LED indicators |
Yes |
| Features |
|---|
| UPS topology |
Line-Interactive |
| Output power capacity |
1 kVA |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Response time |
6 ms |
| Output power |
600 W |
| Input operation voltage (min) |
177 V |
| Input operation voltage (max) |
290 V |
| Surge energy rating |
475 J |
| Waveform |
Pseudo sine |
| Power factor |
0.6 |
| Output voltage regulation |
10% |
| Noise level |
40 dB |
| Ports & interfaces |
|---|
| USB port |
Yes |
| AC outlets quantity |
8 AC outlet(s) |
| Battery |
|---|
| Number of batteries supported |
1 |
| Design |
|---|
| Form factor |
Tower |
| Product colour |
Black |
| Safety |
EN62040- 1:2008+A1:2013 |
| Certification |
EN62040-2:2018 |
| LED indicators |
Yes |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Operating altitude |
0 - 2000 m |
| Technical details |
|---|
| Sustainability compliance |
Yes |
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Width |
345 mm |
| Depth |
200 mm |
| Height |
100 mm |
| Weight |
6.1 kg |
| Certificates |
|---|
| Safety |
EN62040- 1:2008+A1:2013 |
| Certification |
EN62040-2:2018 |
