1100VA, 990 W, 5 Outlets, 2 Batteries, 12 V 9 Ah, 397 × 145 × 220 mm, 12000 g
Key Features
- Pure Sine Wave Output
- Output Power Factor 0.9
- Free, programmable Power Management
- Ultra Modern, Informative LCD – Shows Battery Time Remaining
- ECO Mode
- Smart AVR
- Emergency Power Off Function
- Multiple Communication Available with faster SNMP Card
Description
The new Commander Tower has been developed to provide a better power factor with an all new, modern design and ultra modern, informative LCD display.
Specifications
| Power |
|---|
| Output power capacity |
1.1 kVA |
| Output power |
990 W |
| Input operation voltage (min) |
162 V |
| Input operation voltage (max) |
290 V |
| Output operation voltage (min) |
208 V |
| Output operation voltage (max) |
230 V |
| Emergency Power Off (EPO) |
Yes |
| Power factor |
0.9 |
| Output voltage regulation |
1.5% |
| Crest factor |
3:1 |
| ECO mode |
Yes |
| Input frequency |
50/60 Hz |
| Performance |
|---|
| UPS topology |
Line-Interactive |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Response time |
6 ms |
| Waveform |
Pure sine |
| Power protection features |
Battery discharge, Overcharge, Overload, Short circuit |
| Noise level |
45 dB |
| Features |
|---|
| UPS topology |
Line-Interactive |
| Output power capacity |
1.1 kVA |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Response time |
6 ms |
| Output power |
990 W |
| Input operation voltage (min) |
162 V |
| Input operation voltage (max) |
290 V |
| Output operation voltage (min) |
208 V |
| Output operation voltage (max) |
230 V |
| Emergency Power Off (EPO) |
Yes |
| Waveform |
Pure sine |
| Power protection features |
Battery discharge, Overcharge, Overload, Short circuit |
| Power factor |
0.9 |
| Output voltage regulation |
1.5% |
| Crest factor |
3:1 |
| Noise level |
45 dB |
| ECO mode |
Yes |
| Input frequency |
50/60 Hz |
| Power source type |
AC |
| Ports & interfaces |
|---|
| USB port |
Yes |
| AC outlets quantity |
5 AC outlet(s) |
| AC outlet types |
C13 coupler |
| RS-232 ports |
1 |
| USB port type |
USB Type-B |
| Battery |
|---|
| Number of batteries supported |
2 |
| Battery recharge time |
4 h |
| Battery voltage |
12 V |
| Battery capacity |
9 Ah |
| Design |
|---|
| Form factor |
Tower |
| Product colour |
Black |
| Certification |
EN62040-1 -1 2003, IEC 60950-1 -1, EN62040-2 2006, Directive 2011/65/EU |
| Control type |
Buttons |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
0 - 90% |
| Technical details |
|---|
| Compliance certificates |
RoHS |
| Weight & dimensions |
|---|
| Width |
145 mm |
| Depth |
397 mm |
| Height |
220 mm |
| Weight |
12 kg |
| Certificates |
|---|
| Certification |
EN62040-1 -1 2003, IEC 60950-1 -1, EN62040-2 2006, Directive 2011/65/EU |
