| Display |
|---|
| HDCP |
Yes |
| Display brightness (typical) |
300 cd/m² |
| Screen shape |
Flat |
| Dynamic contrast ratio marketing name |
SmartContrast |
| Display number of colours |
16.7 million colours |
| Native aspect ratio |
16:9 |
| Maximum refresh rate |
75 Hz |
| sRGB coverage (typical) |
107% |
| Display diagonal |
60.5 cm (23.8") |
| Response time |
4 ms |
| Display resolution |
1920 x 1080 pixels |
| Display technology |
LED |
| Contrast ratio (typical) |
1000:1 |
| Contrast ratio (dynamic) |
50000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Horizontal scan range |
30 - 85 kHz |
| Vertical scan range |
48 - 75 Hz |
| Aspect ratio |
16:9 |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| Digital horizontal frequency |
30 - 85 kHz |
| Digital vertical frequency |
48 - 75 Hz |
| Sync-on-green (SOG) |
Yes |
| HD type |
Full HD |
| Supported graphics resolutions |
1920 x 1080 (HD 1080) |
| Pixel density |
93 ppi |
| Display surface |
Matt |
| DDC/CI |
Yes |
| Colour gamut |
91% |
| Backlight type |
W-LED |
| Display panel size |
23.8 inch/60.5 cm |
| Surface hardness |
3H |
| NTSC coverage (typical) |
91% |
| Touchscreen |
No |
| Panel type |
IPS |
| Display diagonal (metric) |
60.5 cm |
| Display sRGB |
Yes |
| Haze rate |
25% |
| LED backlight |
Yes |
| Colour gamut standard |
sRGB, NTSC |
| Anti-glare screen |
Yes |
| Performance |
|---|
| Mean time between failures (MTBF) |
70000 h |
| Compatible operating systems |
Mac OS X; Windows 11/10/8.1/8/7 |
| VESA Adaptive Sync support |
Yes |
| Low Blue Light technology |
Yes |
| Flicker-free technology |
Yes |
| Component video sync |
Separate Sync, Sync-on-green (SOG) |
| EasyRead mode |
Yes |
| Multimedia |
|---|
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| Built-in camera |
No |
| RMS rated power |
4 W |
| Design |
|---|
| Market positioning |
Business |
| Product colour |
Black |
| Heavy metals free |
Hg (mercury) |
| Feet colour |
Black |
| Certification |
CB, EPA, FCC Class B, ICES-003, CE Mark, TUV Ergo, TUV/GS, SEMKO, CU-EAC, CCC, CECP, CEL, UKRAINIAN, TUV Eye Comfort certified |
| Front bezel colour |
Black |
| Detachable stand |
Yes |
| Mean time between failures (MTBF) |
70000 h |
| Exterior finish type |
Textured |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 2 (3.1 Gen 2) |
| USB upstream port type |
USB Type-B |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
4 |
| VGA (D-Sub) ports quantity |
1 |
| DVI port |
Yes |
| DVI-D ports quantity |
1 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
1 |
| HDCP |
Yes |
| Audio input |
No |
| Headphone outputs |
1 |
| Headphone connectivity |
3.5 mm |
| PC Audio in |
Yes |
| Headphone out |
Yes |
| HDMI |
Yes |
| AC (power) in |
Yes |
| I/O ports |
USB-B x 1 (upstream), USB 3.2 x 4 (downstream with 1 fast charge B.C 1.2) |
| HDMI version |
1.4 |
| DisplayPort version |
1.2 |
| HDCP version |
1.4 |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| LED indicators |
Operation, Stand-by |
| Swivelling |
Yes |
| Swivel angle range |
-180 - 180° |
| Tilt angle range |
-5 - 35° |
| Height adjustment |
Yes |
| On Screen Display (OSD) |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Number of OSD languages |
21 |
| On Screen Display (OSD) languages |
Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Russian, Simplified Chinese, Spanish, Swedish, Traditional Chinese, Turkish, Ukrainian |
| Plug and Play |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
15 cm |
| Power |
|---|
| Power supply type |
Internal |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (standby) |
0.35 W |
| Power consumption (typical) |
14.5 W |
| Power consumption (off) |
0 W |
| Power consumption (PowerSave) |
10.4 W |
| Energy efficiency scale |
A+++ to D |
| Energy efficiency class (SDR) |
D |
| Energy consumption (SDR) per 1000 hours |
17 kWh |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
20 - 80% |
| Operating altitude |
0 - 3658 m |
| Non-operating altitude |
0 - 12192 m |
| Weight & dimensions |
|---|
| Width (with stand) |
540 mm |
| Depth (with stand) |
205 mm |
| Height (with stand) |
501 mm |
| Width (without stand) |
540 mm |
| Height (without stand) |
323 mm |
| Depth (without stand) |
51 mm |
| Weight (with stand) |
4.57 kg |
| Weight (without stand) |
2.99 kg |
| Package width |
730 mm |
| Package depth |
139 mm |
| Package height |
450 mm |
| Package weight |
7.36 kg |
| Packaging data |
|---|
| Package type |
Box |
| Package width |
730 mm |
| Package depth |
139 mm |
| Package height |
450 mm |
| Package weight |
7.36 kg |
| Stand included |
Yes |
| Manual |
Yes |
| Cables included |
VGA, HDMI, DisplayPort, Audio (3.5mm), AC |
| Bundled software |
SmartControl |
| Packaging content |
|---|
| Stand included |
Yes |
| Manual |
Yes |
| Cables included |
VGA, HDMI, DisplayPort, Audio (3.5mm), AC |
| Bundled software |
SmartControl |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, TCO |
| Doesn't contain |
Mercury, PVC/BFR |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR, TCO |
| Doesn't contain |
Mercury, PVC/BFR |
| Compliance certificates |
RoHS |
| Power supply type |
Internal |
| Light sensor |
Yes |
| Compatible operating systems |
Mac OS X; Windows 11/10/8.1/8/7 |
| Weight (with stand) |
4.57 kg |
| Surface hardness |
3H |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Touchscreen |
No |
| Other features |
|---|
| Light sensor |
Yes |
| Compatible operating systems |
Mac OS X; Windows 11/10/8.1/8/7 |
| Signal input |
VGA (Analogue); DVI-D (digital, HDCP); DisplayPort 1.2; HDMI 1.4 x 1 |
| Monitor sync input signal |
Separate Sync; Sync on Green |
| Mean time between failures (MTBF) |
70000 h |
| Heavy metals free |
Hg (mercury) |
| Certification |
CB, EPA, FCC Class B, ICES-003, CE Mark, TUV Ergo, TUV/GS, SEMKO, CU-EAC, CCC, CECP, CEL, UKRAINIAN, TUV Eye Comfort certified |
| User controls |
SmartImage; Input; PowerSensor; Menu; Power On/Off |
| Regulatory Approvals |
CB; FCC Class B; ICES-003; CE Mark; TUV Ergo; TUV/GS; CU-EAC; CCC; CECP; CEL; UKRAINIAN; TUV Eye Comfort certified |
| Recyclable packaging material |
100% |
| Picture enhancement |
SmartImage |
| LowBlue mode |
Yes |
| EasyRead mode |
Yes |
| Exterior finish type |
Textured |
| Compliance certificates |
RoHS |
| Width (without stand) |
540 mm |
| Height (without stand) |
323 mm |
| HDMI |
Yes |
| Depth (without stand) |
51 mm |
| Surface hardness |
3H |
| Energy efficiency scale |
A+++ to D |
| Power supply type |
Internal |
| Manual |
Yes |
| Touchscreen |
No |
| Package type |
Box |
| Front bezel colour |
Black |
| Recycling data |
|---|
| Recyclable packaging material |
100% |
| Post-consumer recycled plastic |
85% |
| Certificates |
|---|
| Certification |
CB, EPA, FCC Class B, ICES-003, CE Mark, TUV Ergo, TUV/GS, SEMKO, CU-EAC, CCC, CECP, CEL, UKRAINIAN, TUV Eye Comfort certified |
| Logistics data |
|---|
| Harmonized System (HS) code |
85285210 |
