86", 3840 x 2160, VA, DLED, 16:9, 8GB/128GB, A72×4+A53×4 octa-core, 2.2GHz, Wi-Fi 6, Bluetooth 5.2, Android 14.0
Description
MAXHUB E8630 shines as an exceptional choice, tailored specifically for educational environments. It features
a secure operating system for seamless integration with Google apps and accounts. The AI-powered SoC ensures smooth performance, while the advanced touchscreen allows for natural and precise writing. With versatile
connectivity options, teachers can easily share content from multiple devices. MAXHUB E8630 enhances
classroom collaboration and engagement, making it the perfect choice for educators and students.
Specifications
| Display |
|---|
| Display diagonal |
2.18 m (86") |
| Working area |
1895.04 x 1065.96 mm |
| Contrast ratio (typical) |
3000:1 |
| Touchscreen |
Yes |
| Accuracy touch |
-1.5 - 1.5 mm |
| Number of simultaneous touchpoints |
50 |
| Panel type |
VA |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Response time |
8 ms |
| Display brightness |
400 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| Display number of colours |
1.07 billion colours |
| HD type |
4K Ultra HD |
| LED backlighting type |
Direct-LED |
| Contrast ratio (dynamic) |
50000:1 |
| Maximum refresh rate |
60 Hz |
| Native aspect ratio |
16:9 |
| Low Blue Light technology |
Yes |
| LED backlight |
Yes |
| Features |
|---|
| Display diagonal |
2.18 m (86") |
| Working area |
1895.04 x 1065.96 mm |
| Contrast ratio (typical) |
3000:1 |
| Touchscreen |
Yes |
| Accuracy touch |
-1.5 - 1.5 mm |
| Number of simultaneous touchpoints |
50 |
| Panel type |
VA |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Response time |
8 ms |
| Display brightness |
400 cd/m² |
| Display resolution |
3840 x 2160 pixels |
| Display number of colours |
1.07 billion colours |
| HD type |
4K Ultra HD |
| LED backlighting type |
Direct-LED |
| Contrast ratio (dynamic) |
50000:1 |
| Maximum refresh rate |
60 Hz |
| Native aspect ratio |
16:9 |
| Low Blue Light technology |
Yes |
| LED backlight |
Yes |
| Operating system installed |
Android |
| Computer system |
|---|
| Operating system installed |
Android |
| Built-in processor |
Yes |
| User memory |
128 GB |
| Processor frequency |
2.2 GHz |
| RAM capacity |
8 GB |
| Processor architecture |
ARM Cortex A72 + ARM Cortex A53 |
| Operating system version |
14 |
| Audio |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
4 |
| Projector |
|---|
| Built-in projector |
No |
| Contrast ratio (typical) |
3000:1 |
| Network |
|---|
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Ethernet LAN |
Yes |
| Ports & interfaces |
|---|
| USB 2.0 ports quantity |
1 |
| HDMI ports quantity |
4 |
| Ethernet LAN (RJ-45) ports |
2 |
| RS-232 ports |
1 |
| USB Type-C ports quantity |
2 |
| HDMI output ports quantity |
1 |
| DisplayPorts quantity |
1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
4 |
| VGA (D-Sub) ports quantity |
1 |
| Bluetooth |
Yes |
| Bluetooth version |
5.2 |
| Ethernet LAN |
Yes |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (typical) |
190 W |
| Power consumption (standby) |
0.5 W |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 90% |
| Storage temperature (T-T) |
-20 - 60 °C |
| Storage relative humidity (H-H) |
10 - 90% |
| Technical details |
|---|
| Working area |
1895.04 x 1065.96 mm |
| Touchscreen |
Yes |
| Accuracy touch |
-1.5 - 1.5 mm |
| Panel type |
VA |
| Viewing angle, vertical |
178° |
| Viewing angle, horizontal |
178° |
| Response time |
8 ms |
| Weight & dimensions |
|---|
| Width |
1959 mm |
| Depth |
100 mm |
| Height |
1179 mm |
| Weight |
52.5 kg |
| Packaging data |
|---|
| Package width |
2110 mm |
| Package depth |
225 mm |
| Package height |
1305 mm |
| Package weight |
69 kg |
| Stylus included |
Yes |
| Packaging content |
|---|
| Cables included |
AC, HDMI |
| Stylus included |
Yes |
| Mounting kit |
Yes |
| Mounting brackets included |
Yes |
| Number of stylus pens |
2 |
| Processor |
|---|
| Built-in processor |
Yes |
| Processor frequency |
2.2 GHz |
| Processor architecture |
ARM Cortex A72 + ARM Cortex A53 |
| Memory |
|---|
| User memory |
128 GB |
| RAM capacity |
8 GB |
