98", ADS, 3840 x 2160 (4K UHD), 500 nit, 60 Hz, 8 ms (G to G), Wi-Fi & Bluetooth, 10 W × 2, Pro:Idiom, webOS 6.1
Key Features
- Resolution : 3,840 × 2,160 (UHD)
- Anti-Glare Coating
- Surface Treatment (Haze) : 25%
- Bezel (Width / Depth) : 18 mm (Even) / 68.6 mm
- Operation Time : 24 Hours / 7 Days
Description
UHD Large Screen Signage Display with LG webOS PlatformClear Visibility with Anti-Glare CoatingWith an anti-glare coating and a brightness level of 500 cd/m², content remains clear and vivid even in bright environments.
High-Performance with webOSLG webOS platform enhances user convenience with intuitive GUI and simple app development tools.
Slim DesignBeing slim, a closer installation to the wall is advised. Additionally, this increases the screen’s immersive experience and provides a sophisticated design, improving the installed-space’s décor.
EMC CertifiedWith EMC Class B certification, the UH5Q series meets standards for electromagnetic emissions, supporting safety for both the environment and human health.
Versatile Operation with Multi-USBWith support for two USB ports, the UH5Q offers versatile usage options. For example, operating content on the screen while simultaneously using other connected devices is possible. This includes convenient tasks like downloading PPT files from external storage devices while using a mouse or keyboard during a meeting.
SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fits you.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display number of colours |
1.07 billion colours |
| Display diagonal |
2.49 m (98") |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
500 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1200:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Panel life |
50000 h |
| Touchscreen |
No |
| Panel type |
ADS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Direct-LED |
| Display technology |
LCD |
| Anti-glare screen |
Yes |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| USB connector type |
USB Type-A |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
3 |
| USB port |
Yes |
| DVI port |
No |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
Yes |
| USB version |
2.0 |
| USB ports quantity |
2 |
| RS-232C |
Yes |
| DisplayPorts quantity |
0 |
| Audio Return Channel (ARC) |
Yes |
| Consumer Electronics Control (CEC) |
Yes |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| Orientation |
Horizontal/Vertical |
| Panel mounting interface |
800 x 400 mm |
| Bezel width (top) |
1.8 cm |
| Bezel width (side) |
1.8 cm |
| Bezel width (bottom) |
1.8 cm |
| VESA mounting |
Yes |
| Anti-glare screen |
Yes |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| Panel life |
50000 h |
| Wi-Fi |
Yes |
| Power |
|---|
| Power consumption (typical) |
285 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
385 W |
| Power consumption (economy mode) |
200 W |
| Computer system |
|---|
| Operating system installed |
WebOS |
| Internal memory |
8 GB |
| Operating system version |
6.1 |
| Weight & dimensions |
|---|
| Display width |
2198.9 mm |
| Display depth |
68.6 mm |
| Display height |
1254.6 mm |
| Display weight |
53.6 kg |
| Packaging data |
|---|
| Package width |
2360 mm |
| Package depth |
280 mm |
| Package height |
1425 mm |
| Package weight |
83.9 kg |
| Remote control included |
Yes |
| Cables included |
Power, Phone |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
Power, Phone |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Technical details |
|---|
| VESA mounting |
Yes |
| USB connector type |
USB Type-A |
| Panel type |
ADS |
| LED backlighting type |
Direct-LED |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
Yes |
| Thin Client |
|---|
| Operating system installed |
WebOS |
| Internal memory |
8 GB |
| Sensors |
|---|
| Gyroscope |
Yes |
| Temperature sensor |
Yes |
| Other features |
|---|
| USB connector type |
USB Type-A |
| Wi-Fi |
Yes |
| Power consumption (max) |
385 W |
| Panel type |
ADS |
| Display technology |
LCD |
| Bezel width (top) |
1.8 cm |
| Bezel width (side) |
1.8 cm |
| Bezel width (bottom) |
1.8 cm |
