49" UHD Signage UH7Q-E Series, 3840 x 2160 (UHD), 700 nits (Typ.), 60 Hz, 1200 : 1(TBD)
Key Features
- HDR Support
- webOS Smart Platform
- Slim&Even Bezel
Description
Superb Picture Quality with Ultra HD ResolutionWith the resolution of UHD, it makes the colors and details of the content vivid and realistic.
Even & Slim Bezel DesignThe UH7Q-E series features perfectly balanced horizontal and vertical slim bezels, creating a visually harmonious display solution. Its specialized design simplifies installation in retail environments while delivering a truly immersive viewing experience..
Convenient webOS PlatformThe UH7Q-E is equipped with a high-performance SoC that allows for multiple tasks to be performed without a separate media player. The webOS platform provides app development tools with an intuitive UI that enhances user convenience, and includes webOS partner apps to create an SI-friendly environment.
Comprehensive SecuritywebOS Signage goes beyond security measures at the operating system (OS) level. LG Shield employs a five-tiered defense system, encompassing server, application, operating system, system, and hardware. Each layer operates independently, providing comprehensive protection against various threats. Also webOS platform support ETSI EN 303 645.
SuperSign SolutionsSuperSign is an integrated and intuitive content management solution for creative and organized digital signage content in your space, connecting customers to a range of services with convenient user experiences. There are a variety of versions such as SuperSign Cloud, so discover and enjoy the version that best fitsyou.
Specifications
| Display |
|---|
| LED backlight |
Yes |
| Display number of colours |
1.07 billion colours |
| Display diagonal |
124.5 cm (49") |
| Display resolution |
3840 x 2160 pixels |
| Display brightness |
700 cd/m² |
| HD type |
4K Ultra HD |
| Response time |
8 ms |
| Contrast ratio (typical) |
1100:1 |
| Contrast ratio (dynamic) |
1000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Touchscreen |
No |
| Panel type |
IPS |
| Native aspect ratio |
16:9 |
| LED backlighting type |
Edge-LED |
| Display technology |
LED |
| Colour gamut |
95% |
| Colour depth |
10 bit |
| High Dynamic Range (HDR) supported |
Yes |
| Rated lifetime |
50000 h |
| Native refresh rate |
60 Hz |
| Haze rate |
25% |
| Ports & interfaces |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Ethernet LAN |
Yes |
| HDMI ports quantity |
2 |
| USB port |
Yes |
| DVI port |
No |
| Audio (L/R) out |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Wi-Fi |
No |
| USB version |
2.0 |
| USB ports quantity |
2 |
| RS-232C |
Yes |
| DisplayPorts quantity |
1 |
| USB Power Delivery (USB PD) |
Yes |
| Audio |
|---|
| Number of built-in speakers |
2 |
| RMS rated power |
20 W |
| Built-in speaker(s) |
Yes |
| Design |
|---|
| Product design |
Digital signage flat panel |
| Product colour |
Black |
| Placement supported |
Indoor |
| Panel mounting interface |
300 x 300 mm |
| VESA mounting |
Yes |
| Bezel colour |
Black |
| Wall mountable |
Yes |
| Performance |
|---|
| Purpose |
Universal |
| Operating hours (hours/days) |
24/7 |
| International Protection (IP) code |
IP5X |
| On Screen Display (OSD) languages |
Multi |
| Plug and Play |
Yes |
| Security algorithms |
SNMP |
| Wi-Fi |
No |
| Power |
|---|
| Power consumption (typical) |
87 W |
| Power consumption (standby) |
0.5 W |
| AC input voltage |
100-240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (off) |
0.5 W |
| Power consumption (max) |
134 W |
| Energy efficiency class (SDR) |
G |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
86.7 kWh |
| Computer system |
|---|
| Computer system |
Yes |
| Computer system type |
System on Chip (SoC) |
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Built-in processor |
No |
| Operating system version |
8.0 |
| Weight & dimensions |
|---|
| Display width |
1104.3 mm |
| Display depth |
29.7 mm |
| Display height |
645.5 mm |
| Display weight |
13.6 kg |
| Packaging data |
|---|
| Package width |
1215 mm |
| Package depth |
142 mm |
| Package height |
742 mm |
| Package weight |
16.1 kg |
| Remote control included |
Yes |
| Cables included |
AC, USB Type-C |
| Packaging content |
|---|
| Remote control included |
Yes |
| Cables included |
AC, USB Type-C |
| Tilt angle |
15° |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Technical details |
|---|
| VESA mounting |
Yes |
| USB connector type |
USB Type-A, USB Type-C |
| Power supply type |
Internal |
| Bezel width |
1.14 cm |
| Panel type |
IPS |
| LED backlighting type |
Edge-LED |
| Sustainability certificates |
ErP, ENERGY STAR |
| Compliance certificates |
Federal Communications Commission (FCC), KC, CE |
| Network |
|---|
| Ethernet LAN |
Yes |
| Wi-Fi |
No |
| Security algorithms |
SNMP |
| Thin Client |
|---|
| Operating system installed |
WebOS |
| Internal memory |
16 GB |
| Brand-specific features |
|---|
| LG technologies (AV/TV) |
Smart Energy Saving, Local Network Sync, Control Manager, Local Contents Scheduling, Booting Logo Image, Video Tag, Gapless Playback, ISM Method, Group Manager, No Signal Image, RS232C Sync, Status Mailing, Setting Data Cloning, Fail over, SI Server Setting |
| Sensors |
|---|
| Temperature sensor |
Yes |
| Features |
|---|
| Wall mountable |
Yes |
| Other features |
|---|
| USB connector type |
USB Type-A, USB Type-C |
| Power supply type |
Internal |
| Bezel width |
1.14 cm |
| Wi-Fi |
No |
| Safety |
CB / NRTL |
| Power consumption (max) |
134 W |
| Panel type |
IPS |
| Display technology |
LED |
| Plug and Play |
Yes |
