60.5cm (23.8") Full HD 1920 x 1080 W-LED IPS, 16:9, 250cd/m², 16.7M, 178°/178°, 1500:1
Key Features
- 60.5cm (23.8") Full HD 1920 x 1080 W-LED IPS
- 16:9, 250cd/m², 1500:1
- USB, HDMI, DisplayPort
Description
Lenovo ThinkVision T24D-4V 23.8'24' FHD IPS Monitor 1920x1080 16:9 Height Adjustable Tilt Swivel Pivot DP HDMI USB-C LAN USB3.2 Hub built-in Webcam Speaker VESA 3yr
PERFORMANCE
Display Size 23.8'
View Area 527x296.5 mm
Panel In-Plane Switching
Backlight WLED
Aspect Ratio 16:09
Resolution 1920x1080
Pixel Pitch 0.2745x0.2745 mm
Dot / Pixel Per Inch 93 dpi
View Angle (H / V) 178° / 178°
Response Time 4ms GtG (Extreme mode) / 6ms GtG (Typical mode)
Color Support 16.7 Million
Refresh Rate 48Hz - 120Hz
Brightness 250 cd/m²
Contrast Ratio 1500:01:00
Color Gamut 99% sRGB, 99%BT.709
Screen Surface Treatment Anti-glare
Curvature None
Camera Integrated webcam (5MP, IR+RGB)
Microphone Integrated Microphone
Speakers 5Wx2
Power Consumption (Typical / Maximum) 16W / 165W
Power Adapter Integrated
Touchscreen None
Smart System None
DESIGN
Stand Tilt, Swivel, Pivot, Height Adjust Stand
Case Color Eclipse Black
Side Bezel Width 2 mm
Mounting Supports VESA mount 100 x 100 mm
ThinkCentre M Series Support Tiny Support
Pen None
Dimensions (WxDxH) Lowest Position | 539.8 x 190.0 x 385.2 mm (21.25 x 7.48 x 15. inches)
Highest Position | 539.8 x 190.0 x 540.2 mm (21.25 x 7.48 x 21.27 inches)
Head Only | 539.8 x 50.0 x 362.7 mm (21.25 x 1.97 x 14.28 inches)
Packaging Dimensions (WxDxH) 730.0 x 111.0 x 450.0 mm (28.74 x 4.37 x 17.72 inches)
Weight Monitor With Stand | 5.9 kg (13 lbs)
Monitor Only | 3.8 kg (8.4 lbs)
Packaging Weight 8.4 kg (18.5 lbs)
CONNECTIVITY
USB Port 1x USB-C® (USB 5Gbps, PD 3.0 100W, USB upstream), 3x USB-A (USB 5Gbps, 1x BC 1.2, USB downstream), 1x USB-C (USB 5Gbps, 15W PD, USB downstream)
Video Connector 1x HDMI® 2.1 TMDS, 1x DP 1.4 (HBR2), 1x DP 1.4 Out, 1x USB-C® (DP 1.4 Alt Mode HBR2)
Network Connectivity 1x RJ45, Ethernet (10M/100M/1000M)
SERVICE
Base Warranty 3-year
Specifications
| Display |
|---|
| Display brightness (typical) |
250 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colours |
| Native aspect ratio |
16:9 |
| Maximum refresh rate |
120 Hz |
| sRGB coverage (typical) |
99% |
| Display diagonal |
60.5 cm (23.8") |
| Response time |
6 ms |
| Display resolution |
1920 x 1080 pixels |
| Display technology |
LED |
| Contrast ratio (typical) |
1500:1 |
| Contrast ratio (dynamic) |
3000000:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2745 x 0.2745 mm |
| Viewable size, horizontal |
52.7 cm |
| Viewable size, vertical |
29.6 cm |
| HD type |
Full HD |
| Pixel density |
93 ppi |
| Colour gamut |
99% |
| Backlight type |
W-LED |
| Response time (fast) |
4 ms |
| Touchscreen |
No |
| Panel type |
IPS |
| Colour depth |
8 bit |
| LED backlight |
Yes |
| Response time measurement type |
GTG (Gray to Gray) |
| Anti-glare screen |
Yes |
| Performance |
|---|
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Low Blue Light technology |
Yes |
| Multimedia |
|---|
| Number of speakers |
2 |
| Built-in speaker(s) |
Yes |
| Built-in camera |
Yes |
| RMS rated power |
5 W |
| Megapixel (approx.) |
5 MP |
| Built-in microphone |
Yes |
| Power |
|---|
| Power cable length |
1.8 m |
| Power supply type |
Internal |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
165 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
16 W |
| Power consumption (off) |
0.5 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
E |
| Energy efficiency class (HDR) |
Not available |
| Energy consumption (SDR) per 1000 hours |
16 kWh |
| Design |
|---|
| Market positioning |
Office |
| Product colour |
Black |
| Feet colour |
Black |
| Certification |
EU Energy Label (E-class)
TCO Certified, generation 10
TCO Edge 2.1
Volatile Organic Compound Certification
Eyesafe Certified 2.0
Microsoft Teams Certification
TÜV Rheinland Eye Comfort Certification (5-star)
TÜV Rheinland Low Blue Light (Hardware Solution) |
| Front bezel colour |
Black |
| Colour name |
Eclipse Black |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB hub version |
3.2 Gen 1 (3.1 Gen 1) |
| USB upstream port type |
USB Type-C |
| Number of upstream ports |
1 |
| USB Type-A downstream ports quantity |
3 |
| USB Type-C downstream ports quantity |
1 |
| VGA (D-Sub) ports quantity |
0 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
2 |
| Headphone connectivity |
3.5 mm |
| Headphone out |
Yes |
| HDMI |
Yes |
| HDMI version |
2.1 |
| DisplayPort version |
1.4 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
100 W |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Number of USB Type-C upstream ports quantity |
1 |
| DisplayPort out quantity |
1 |
| DisplayPort out version |
1.4 |
| Ethernet LAN |
Yes |
| Network |
|---|
| Ethernet LAN |
Yes |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt angle range |
-5 - 23.5° |
| Height adjustment |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
15.5 cm |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 60 °C |
| Operating relative humidity (H-H) |
10 - 80% |
| Storage relative humidity (H-H) |
5 - 95% |
| Weight & dimensions |
|---|
| Width (with stand) |
539.8 mm |
| Depth (with stand) |
190 mm |
| Height (with stand) |
540.2 mm |
| Bezel width (side) |
2 mm |
| Bezel width (top) |
2 mm |
| Bezel width (bottom) |
4.08 cm |
| Width (without stand) |
539.8 mm |
| Height (without stand) |
362.7 mm |
| Depth (without stand) |
50 mm |
| Weight (with stand) |
5.9 kg |
| Package width |
730 mm |
| Package depth |
111 mm |
| Package height |
450 mm |
| Package weight |
8.4 kg |
| Packaging data |
|---|
| Package width |
730 mm |
| Package depth |
111 mm |
| Package height |
450 mm |
| Package weight |
8.4 kg |
| Stand included |
Yes |
| Power cable length |
1.8 m |
| Cables included |
AC, DisplayPort, USB Type-C to USB Type-C |
| DisplayPort cable length |
1.8 m |
| Packaging content |
|---|
| Stand included |
Yes |
| Power cable length |
1.8 m |
| Cables included |
AC, DisplayPort, USB Type-C to USB Type-C |
| DisplayPort cable length |
1.8 m |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold |
| Compliance certificates |
RoHS |
| Power supply type |
Internal |
| Weight (with stand) |
5.9 kg |
| Touchscreen |
No |
| Other features |
|---|
| Certification |
EU Energy Label (E-class)
TCO Certified, generation 10
TCO Edge 2.1
Volatile Organic Compound Certification
Eyesafe Certified 2.0
Microsoft Teams Certification
TÜV Rheinland Eye Comfort Certification (5-star)
TÜV Rheinland Low Blue Light (Hardware Solution) |
| Compliance certificates |
RoHS |
| Power consumption (max) |
165 W |
| Width (without stand) |
539.8 mm |
| Height (without stand) |
362.7 mm |
| HDMI |
Yes |
| Depth (without stand) |
50 mm |
| USB Power Delivery up to |
100 W |
| Energy efficiency scale |
A to G |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Power supply type |
Internal |
| Power cable length |
1.8 m |
| Ethernet LAN |
Yes |
| Touchscreen |
No |
| USB Power Delivery (USB PD) |
Yes |
| Front bezel colour |
Black |
| Certificates |
|---|
| Certification |
EU Energy Label (E-class)
TCO Certified, generation 10
TCO Edge 2.1
Volatile Organic Compound Certification
Eyesafe Certified 2.0
Microsoft Teams Certification
TÜV Rheinland Eye Comfort Certification (5-star)
TÜV Rheinland Low Blue Light (Hardware Solution) |
