60.5cm (23.8") Quad HD 2560 x 1440 W-LED IPS, 16:9, 300cd/m², 16.7M, 6ms, 178°/178°, 1500:1
Key Features
- 60.5cm (23.8") Quad HD 2560 x 1440 W-LED IPS
- 6ms, 16:9, 300cd/m², 1500:1
- USB, HDMI, DisplayPort
Description
Lenovo ThinkVision P24qd-40 23.8' 24' 24' QHD IPS Monitor 2K 2560x1440 16:9 Height Adjustable Tilt Swivel Pivot HDMI DP1.4 DP 4xUSB3.2 Hub Etherne 3yr
PERFORMANCE
Display Size 23.8“
View Area 526.8x296.4 mm
Panel In-Plane Switching
Backlight WLED
Aspect Ratio 16:09
Resolution 2560x1440
Pixel Pitch 0.2058x0.2058 mm
Dot / Pixel Per Inch 123 dpi
View Angle (H / V) 178° / 178°
Response Time 4ms GtG (Extreme mode) / 6ms GtG (Typical mode)
Color Support 16.7 Million
Refresh Rate 48Hz - 120Hz
Brightness 300 cd/m²
Contrast Ratio 1500:01:00
Color Gamut 99% sRGB, 99% BT.709
Screen Surface Treatment Anti-glare
Curvature Flat Panel
Camera Modular Camera Support
Microphone None
Speakers Modular Speaker Support
Power Consumption (Typical / Maximum) 16.5W / 210W
Power Adapter Integrated
DESIGN
Stand Tilt, Swivel, Pivot, Height Adjust Stand
Case Color Eclipse Black
Side Bezel Width 2 mm
Mounting Supports VESA mount 100 x 100 mm
ThinkCentre M Series Support Tiny Support
Dimensions (WxDxH) Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches)
Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches)
Head Only | 539.8 x 45.3 x 315.8 mm (21.25 x 1.78 x 12.43 inches)
Packaging Dimensions (WxDxH) 730 x 123 x 420 mm (28.74 x 4.84 x 16.54 inches)
Weight Monitor With Stand | 5.6 kg (12.4 lbs)
Monitor Head Only | 3.6 kg (8.0 lbs)
Packaging Weight 8.4 kg (18.4 lbs)
CONNECTIVITY
USB Port x USB-C® (USB 10Gbps,DP 1.4 Alt Mode HBR3, PD3.1 140W, USB upstream), 1x USB-B (USB 5Gbps, USB upstream), 4x USB-A (USB 5Gbps, 1x BC1.2, USB downstream), 1x USB-C (USB 5Gbps, 15WPD, USB downstream)
Video Connector 1x HDMI® 2.1 TMDS, 1x DP 1.4 (HBR3), 1x DP 1.4 Out, 1x USB-C® (10Gbps, DP 1.4 Alt Mode HBR3)
Network Connectivity 1x RJ45, Ethernet (10M/100M/1000M/2500M)
SERVICE
Base Warranty 3-year
CERTIFICATIONS
Environmental Certification ENERGY STAR® Certified, TCO 10, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT™ Gold, Volatile Organic Compound Certification, RoHS
Ergonomic Certification TÜV Rheinland® Eye Comfort 5 Stars, Eyesafe® Display 2.0, TÜV Low Blue Light (Hardware solution)
Sync Technology None
Special Features HDR10 Compliance
Factory Calibration: Avg. Delta E<2 at sRGB
Lenovo® ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows® 10 & 11, Mac OS (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center.
KVM Switch (with eKVM)
LDFM (Lenovo® Display Fleet Manager)
Mirrored Power Button
Multi-sync
Natural Low Blue Light
Smart Power
SOFTWARE
Operating System Support Windows® 10, Windows 11
Specifications
| Display |
|---|
| Display brightness (typical) |
300 cd/m² |
| Screen shape |
Flat |
| Display number of colours |
16.7 million colours |
| Native aspect ratio |
16:9 |
| Maximum refresh rate |
120 Hz |
| sRGB coverage (typical) |
99% |
| Display diagonal |
60.5 cm (23.8") |
| Response time |
6 ms |
| Display resolution |
2560 x 1440 pixels |
| Display technology |
LCD |
| Contrast ratio (typical) |
1500:1 |
| Viewing angle, horizontal |
178° |
| Viewing angle, vertical |
178° |
| Pixel pitch |
0.2058 x 0.2058 mm |
| Viewable size, vertical |
52.7 cm |
| Viewable size diagonal |
29.6 cm |
| HD type |
Quad HD |
| Pixel density |
123 ppi |
| Colour gamut |
99% |
| Backlight type |
W-LED |
| Response time (fast) |
4 ms |
| Touchscreen |
No |
| High Dynamic Range (HDR) supported |
Yes |
| Panel type |
IPS |
| Colour depth |
8 bit |
| High Dynamic Range (HDR) technology |
High Dynamic Range 10 (HDR10) |
| LED backlight |
Yes |
| Colour gamut standard |
Rec. 709 |
| Anti-glare screen |
Yes |
| Network |
|---|
| Ethernet LAN data rates |
2500 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Ethernet LAN |
Yes |
| Performance |
|---|
| AMD FreeSync |
No |
| NVIDIA G-SYNC |
No |
| Windows operating systems supported |
Windows 10, Windows 11 |
| Low Blue Light technology |
Yes |
| Multimedia |
|---|
| Built-in speaker(s) |
No |
| Built-in camera |
No |
| Power |
|---|
| Power cable length |
1.8 m |
| Power supply type |
Internal |
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power consumption (max) |
210 W |
| Power consumption (standby) |
0.5 W |
| Power consumption (typical) |
16.5 W |
| Power consumption (off) |
0.3 W |
| Energy efficiency scale |
A to G |
| Energy efficiency class (SDR) |
D |
| Energy efficiency class (HDR) |
F |
| Energy consumption (SDR) per 1000 hours |
14 kWh |
| Energy consumption (HDR) per 1000 hours |
22 kWh |
| Design |
|---|
| Product colour |
Black |
| Feet colour |
Black |
| Certification |
ENERGY STAR Certified,TCO 10.0, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT Gold
TÜV Rheinland Eye Comfort 5 Stars, Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution) |
| Colour name |
Eclipse Black |
| Ports & interfaces |
|---|
| Built-in USB hub |
Yes |
| USB upstream port type |
USB Type-B, USB Type-C |
| Number of upstream ports |
2 |
| USB Type-A downstream ports quantity |
4 |
| HDMI ports quantity |
1 |
| DisplayPorts quantity |
2 |
| Headphone out |
No |
| HDMI |
Yes |
| HDMI version |
2.1 |
| DisplayPort version |
1.4 |
| USB Power Delivery (USB PD) |
Yes |
| USB Power Delivery up to |
140 W |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Number of USB Type-B upstream ports quantity |
1 |
| Number of USB Type-C upstream ports quantity |
1 |
| DisplayPort out quantity |
1 |
| DisplayPort out version |
1.4 |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
2500 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Ergonomics |
|---|
| VESA mounting |
Yes |
| Cable lock slot |
Yes |
| Panel mounting interface |
100 x 100 mm |
| Swivelling |
Yes |
| Swivel angle range |
-45 - 45° |
| Tilt angle range |
-5 - 23.5° |
| Height adjustment |
Yes |
| Pivot angle |
-90 - 90° |
| Pivot |
Yes |
| Cable lock slot type |
Kensington |
| Tilt adjustment |
Yes |
| Adjustable height (max) |
15.5 cm |
| Weight & dimensions |
|---|
| Width (with stand) |
539.8 mm |
| Depth (with stand) |
190 mm |
| Height (with stand) |
505.8 mm |
| Bezel width (side) |
2 mm |
| Bezel width (top) |
2 mm |
| Bezel width (bottom) |
1.15 cm |
| Width (without stand) |
539.8 mm |
| Height (without stand) |
315.8 mm |
| Depth (without stand) |
45.3 mm |
| Weight (with stand) |
5.6 kg |
| Weight (without stand) |
3.6 kg |
| Package width |
730 mm |
| Package depth |
123 mm |
| Package height |
420 mm |
| Package weight |
8.4 kg |
| Packaging data |
|---|
| Package width |
730 mm |
| Package depth |
123 mm |
| Package height |
420 mm |
| Package weight |
8.4 kg |
| Stand included |
Yes |
| Power cable length |
1.8 m |
| Quick start guide |
Yes |
| Cables included |
DisplayPort, Power, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
| DisplayPort cable length |
1.8 m |
| Packaging content |
|---|
| Stand included |
Yes |
| Power cable length |
1.8 m |
| Quick start guide |
Yes |
| Cables included |
DisplayPort, Power, USB Type-A to USB Type-B, USB Type-C to USB Type-C |
| DisplayPort cable length |
1.8 m |
| Other features |
|---|
| Certification |
ENERGY STAR Certified,TCO 10.0, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT Gold
TÜV Rheinland Eye Comfort 5 Stars, Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution) |
| Ethernet LAN data rates |
2500 Mbit/s |
| Ethernet LAN (RJ-45) ports |
1 |
| Power consumption (max) |
210 W |
| Width (without stand) |
539.8 mm |
| Quick start guide |
Yes |
| Height (without stand) |
315.8 mm |
| HDMI |
Yes |
| Depth (without stand) |
45.3 mm |
| USB Power Delivery up to |
140 W |
| Energy efficiency scale |
A to G |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| Power supply type |
Internal |
| Power cable length |
1.8 m |
| Ethernet LAN |
Yes |
| Touchscreen |
No |
| USB Power Delivery (USB PD) |
Yes |
| Certificates |
|---|
| Certification |
ENERGY STAR Certified,TCO 10.0, TCO Edge 2.1, EU Energy Efficiency Level (Level-D), EPEAT Gold
TÜV Rheinland Eye Comfort 5 Stars, Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution) |
| Technical details |
|---|
| Power supply type |
Internal |
| Weight (with stand) |
5.6 kg |
| Touchscreen |
No |
