AMD Ryzen 7 250 (3.3GHz), 16GB DDR5-SDRAM, 512GB SSD, 16" WUXGA 1920 x 1200 IPS, AMD Radeon 780M, LAN, WLAN, Webcam, Windows 11 Pro 64-bit
Key Features
- Windows 11 Pro 64-bit
- AMD Ryzen 7 250 (3.3GHz)
- 16" WUXGA 1920 x 1200 IPS
- 16GB (5600MHz) DDR5-SDRAM (1 x 16) & 512GB SSD
Description
LENOVO ThinkBook 16 G9 16' WUXGA AMD Ryzen 7 250 16GB DDR5 512GB SSD Windows 11 PRO Radeon 780M GPU Thunderbolt Fingerprint 1YROS 1.7kg
PERFORMANCE
Processor AMD Ryzen™ 7 250 (8C / 16T, 3.3 / 5.1GHz, 8MB L2 / 16MB L3)
AI PC Category AI PC
NPU Integrated AMD Ryzen™ AI, up to 16 TOPS
Graphics Integrated AMD Radeon™ 780M Graphics
Chipset AMD SoC Platform
Memory 1x 16GB SODIMM DDR5-5600
Memory Slots Two DDR5 SODIMM slots, dual-channel capable
Max Memory Up to 64GB DDR5-5600
Storage 512GB SSD M.2 2242 PCIe® 4.0x4 NVMe®
Storage Slot Two M.2 slots • One M.2 2242 PCIe® 4.0 x4 slot • One M.2 2280 PCIe® 4.0 x4 slot
Max Storage Support Up to two drives, 2x M.2 SSD • M.2 2242 SSD up to 2TB • M.2 2280 SSD up to 2TB
Card Reader SD Card Reader
Audio Chip High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers Stereo speakers, 2W x2, Dolby Audio™
Microphone 2x, Array
Camera FHD 1080p + IR Hybrid with Privacy Shutter
Battery 48Wh
Power Adapter 65W USB-C® (3-pin)
Special Features Modern Standby
DESIGN
Display 16' WUXGA (1920x1200) IPS 400nits Anti-glare, 45% NTSC, 60Hz
Touchscreen None
Screen-to-Body Ratio 90%
Color Calibration No Color Calibration
Pen Pen Not Supported
Keyboard Backlit, English
Touchpad Buttonless Mylar® surface multi-touch touchpad, supports Precision TouchPad (PTP), 75 x 120 mm (2.95 x 4.72 inches)
Dimensions (WxDxH) 356 x 253.5 x 17.5 mm (14.01 x 9.98 x 0.69 inches)
Weight Starting at 1.7 kg (3.75 lbs)
Case Color Arctic Grey
Case Material Aluminium (Top), PC-ABS (Bottom)
Surface Treatment Anodizing Sandblasting (Top), Texture (Bottom)
SOFTWARE
Operating System Windows® 11 Pro, English (US) / English (UK)
Bundled Software Office Trial
CONNECTIVITY
WLAN + Bluetooth Wi-Fi® 6, 802.11ax 2x2 + BT5.2
WWAN WWAN Not Supported
Ethernet 100/1000M (RJ-45)
Standard Ports 1x USB-A (USB 5Gbps), Always On
1x USB-A (USB 5Gbps)
2x USB-C® (USB4® 40Gbps), with USB PD 45-65W and DisplayPort™ 1.4a
1x HDMI® 2.1, up to 4K/60Hz
1x Headphone / microphone combo jack (3.5mm)
1x Ethernet (RJ-45)
1x SD card reader
Docking Various docking solutions supported via USB-C®. For more compatible docking solutions, please visit Docking for ThinkBook® 16 G9 AHP
SECURITY & PRIVACY
Security Chip Discrete TPM 2.0 Enabled
Physical Locks Kensington Nano Security Slot™, 2.5 x 6 mm
Fingerprint Reader Touch Style, Match-on-Chip, Integrated in Power Button
Other Security Camera privacy shutter
IR camera for Windows® Hello (facial recognition)
Included Upgrade 1Y Onsite
Specifications
| Design |
|---|
| Colour name |
Arctic Grey |
| Product type |
Laptop |
| Product colour |
Grey |
| Form factor |
Clamshell |
| Housing material |
Acrylonitrile butadiene styrene (ABS), Aluminium, Polycarbonate (PC) |
| Certified refurbished |
No |
| Display back cover material |
Aluminium |
| Display |
|---|
| HD type |
WUXGA |
| Display diagonal |
40.6 cm (16") |
| Display resolution |
1920 x 1200 pixels |
| Touchscreen |
No |
| LED backlight |
Yes |
| Display brightness |
400 cd/m² |
| Panel type |
IPS |
| Contrast ratio (typical) |
1000:1 |
| Anti-glare screen |
Yes |
| Maximum refresh rate |
60 Hz |
| RGB colour space |
NTSC |
| Colour gamut |
45% |
| Native aspect ratio |
16:10 |
| Processor |
|---|
| Processor generation |
AMD Ryzen 200 Series |
| Processor cache type |
L2 & L3 |
| Processor frequency |
3.3 GHz |
| Processor family |
AMD Ryzen™ 7 |
| Processor model |
250 |
| Processor boost frequency |
5.1 GHz |
| Processor cores |
8 |
| Processor threads |
16 |
| L3 cache |
16 MB |
| L2 cache |
8 MB |
| Motherboard chipset |
AMD SoC |
| Processor manufacturer |
AMD |
| Processor base power |
28 W |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
AMD Ryzen AI |
| Total processor performance up to |
38 TOPs |
| NPU performance up to |
16 TOPs |
| Memory |
|---|
| Internal memory |
16 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory clock speed |
5600 MHz |
| Memory layout (slots x size) |
1 x 16 GB |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
64 GB |
| Memory form factor |
SO-DIMM |
| Memory channels |
Dual-channel |
| Storage |
|---|
| SSD form factor |
M.2 |
| Optical drive type |
No |
| Total storage capacity |
512 GB |
| Storage media |
SSD |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| SSD interface |
PCI Express 4.0 |
| Card reader integrated |
Yes |
| Compatible memory cards |
SD |
| Total SSDs capacity |
512 GB |
| NVMe |
Yes |
| M.2 SSD size |
2242 (22 x 42 mm) |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card family |
AMD Radeon Graphics |
| On-board graphics card model |
AMD Radeon 780M |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| On-board GPU manufacturer |
AMD |
| Audio |
|---|
| Audio chip |
Realtek ALC3287 |
| Number of microphones |
2 |
| Audio system |
Dolby Audio |
| Number of built-in speakers |
2 |
| Speaker power |
2 W |
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Front camera resolution |
1920 x 1080 pixels |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Front camera HD type |
Full HD |
| Infrared (IR) camera |
Yes |
| Windows Hello |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6 (802.11ax) |
| Bluetooth |
Yes |
| Wi-Fi standards |
Wi-Fi 6 (802.11ax) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
100,1000 Mbit/s |
| Bluetooth version |
5.2 |
| WWAN |
Not installed |
| Antenna type |
2x2 |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| USB Sleep-and-Charge ports |
1 |
| USB Sleep-and-Charge |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| USB4 Gen 3x2 ports quantity |
2 |
| Performance |
|---|
| Motherboard chipset |
AMD SoC |
| Keyboard |
|---|
| Pointing device |
Touchpad |
| Numeric keypad |
Yes |
| Keyboard backlit |
Yes |
| Keyboard language |
English |
| Software |
|---|
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Operating system language |
ENG-UK, US English |
| Bundled software |
Office Trial |
| Trial software |
Office |
| Battery |
|---|
| Battery technology |
Lithium-Ion (Li-Ion) |
| Battery capacity |
48 Wh |
| Fast charging |
Yes |
| Fast charging time (50%) |
30 min |
| Power |
|---|
| AC adapter power |
65 W |
| AC adapter frequency |
50/60 Hz |
| AC adapter input voltage |
100 - 240 V |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C charging port |
Yes |
| USB Type-C required charging power (min) |
45 W |
| USB Type-C required charging power (max) |
65 W |
| Security |
|---|
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Fingerprint reader |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Windows Hello |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
5 - 35 °C |
| Storage temperature (T-T) |
5 - 43 °C |
| Operating relative humidity (H-H) |
8 - 95% |
| Storage relative humidity (H-H) |
5 - 95% |
| Maximum shipping altitude |
3048 m |
| Certificates |
|---|
| Certification |
ErP Lot 6/26
TCO Certified, generation 10
MIL-STD-810H
TÜV Rheinland Low Blue Light (Software Solution) |
| Compliance certificates |
RoHS |
| Sustainability |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold |
| Weight & dimensions |
|---|
| Weight |
1.7 kg |
| Width |
356 mm |
| Depth |
253.5 mm |
| Height |
17.5 mm |
| Packaging data |
|---|
| AC adapter included |
Yes |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Technical details |
|---|
| Sustainability certificates |
ENERGY STAR, EPEAT Gold |
| Compliance certificates |
RoHS |
| Other features |
|---|
| Audio system |
Dolby Audio |
| On-board graphics card |
Yes |
| Maximum shipping altitude |
3048 m |
| AC adapter included |
Yes |
| Anti-glare screen |
Yes |
