HPE MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller

MR408i-o Gen11 x8 Lanes 4GB Cache OCP SPDM Storage Controller

Key Features

• Standard PCI HH/HL and OCP NIC 3.0 form factors
• DMTF Security Protection Data Model (SPDM) supports certificate-based authentication with HPE iLO6
• Hardware Root of Trust (HWRoT) protects against malicious firmware
• MRSA, StorCLI, UEFI, and Redfish Management

Reasons To Buy

Powerful Performance

HPE Compute MR Controllers offer up to 13.7 GB/s of bandwidth, and eight PCIe Gen4 host lanes.
HPE Compute MR Controllers offer 3M Random Read IOPS and 240K RAID5 Random Write IOPS.
MR932i-p now offers 16 PCIe Gen5 host lanes with 32G NVMe and 24G SAS speeds.
MR932i-p PQC now offers security enablement for PQC 2030 requirements.

Enhanced Security

HPE Compute MR Controllers are built with the HPE Silicon Root of Trust for firmware authentication and support for self-encrypting drives to help protect data at rest and prevent malware.
HPE Compute MR Controllers now offer DMTF SPDM that supports certificate-based authentication with HPE iLO 6.

Software Supported

HPE Compute MR Controllers support full tool suite including command line interface, web-based management, and out-of-band management support.
Supported operating systems include, but are not limited to Windows, Linux, and VMware.

Description

Do you need a versatile, simplified, and flexible choice for your data centers? HPE Compute MR Controllers are expansive and agile PCIe Gen4 (PCIe Gen5 for MR932i-p) storage controllers based on Broadcom MegaRAID technology that deliver quality, performance, and security for mission-critical applications. The MR416i-o and MR416i-p controllers are ideal for most data center environments where RAID is applicable offering reduced rebuild times, high bandwidth, and 240K RAID5 Random Write IOPS. The MR416i-o and MR416i-p controllers are ideal for many virtualized environments where HBA / pass-through mode is applicable offering high bandwidth and three million random write IOPS. HPE Compute MR Controllers offer solutions for multiple workflows across multiple applications to deliver customer satisfaction. For those requiring PQC security within their installation, MR932i-p PQC is available.

What is new supporting point:
MR932i-p PQC enables security for PQC 2030 requirements.
MR932i-p with PCIe Gen5 speeds (32G NVMe and 24G SAS) and does not support SATA SSDs nor SATA/SAS HDDs.
Standard PCI HH/HL and OCP NIC 3.0 form factors.
DMTF Security Protocol Data Model (SPDM) supports certificate-based authentication with HPE iLO 6.
Hardware Root of Trust (HWRoT) protects against malicious firmware.
MegaRAID Storage Administrator (MRSA), Storage Command Line Interface (StorCLI), Unified Extensible Firmware Interface (UEFI), and Redfish management.

Specifications

Ports & interfaces
Supported storage drive interfaces	SAS, Serial ATA III
Performance
RAID levels	0, 1, 5, 10, 6, 50, 60
Internal memory	4098 MB
Certification	Refer to HPE Compute MR Controllers QuickSpecs
Other features
Chassis type	OCP NIC 3.0 form-factor
I/O ports	2x 8 LP SlimSAS
