3LCD, 0.62-inch, Full HD, 4100 lm, HDMI, 2 x D-sub 15pin (video in), 1 x D-sub 9pin, RJ45, USB type A, USB type B, RCA , 282 x 309 x 90 mm, 3.1 kg
Key Features
- 4,100-lumen brightness
- Sharp images and vivid colours
- Full HD resolution
- Enjoy full HD crisp images
- Stream and share connectivity
- Built-in wireless connectivity and Screen Mirroring
- Collaborative features
- iProjection App, split-screen function, moderator function
Description
- Up to 3x brighter colours and reliable performance1 – 3LCD, 3-chip technology
- 1080p high definition – for full HD presentations, videos, images, digital signage and more
- Amazing colour brightness – up to 4,100 lumens colour brightness and 4,100 lumens white brightness
- Miracast support – project your smartphone or tablet screens without a cable connection
- Airplay support – project your Mac OS laptop or iOS mobile device screens without a cable connection
- Split screen – project from two different image sources for flexible options in the workplace
- Ultra-portable – weighing in at only 3.1 kg for easy travel between home and the office
- Captivating sound – enjoy a built-in stereo speaker up to 16 W for life-like sound
- Wireless LAN Enterprise Security – connect projectors in a secure wireless network environment
- Simple set-up – auto vertical correction and easy-slide horizontal image correction to help get up and running in no time
- Low cost of ownership – long-life, cost efficient lamps and a high efficiency filter extends the life of your projector and allows for hassle free maintenance
- Easy to use – a new simple welcome guide and easy-to-use remote puts all the most commonly used functions right at your fingertips
- Auto power on – simply plug-in a HDMI, USB or VGA cable to turn the projector on
- Up to 3 year projector warranty – enjoy peace of mind
Specifications
| Projector |
|---|
| Number of colours |
1.07 billion colours |
| Projector brightness |
4100 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
1080p (1920x1080) |
| Screen size compatibility |
787.4 - 7721.6 mm (31 - 304") |
| Native aspect ratio |
16:9 |
| Projection distance |
0.88 - 14.29 m |
| Projection distance (wide) |
0.9 - 8.9 m |
| Projection distance (tele) |
1.4 - 14.3 m |
| Contrast ratio (typical) |
16000:1 |
| Matrix size |
1.57 cm (0.62") |
| Keystone correction, vertical |
-30 - 30° |
| Keystone correction, horizontal |
-30 - 30° |
| Smart projector |
No |
| Light source |
|---|
| Light source type |
Lamp |
| Service life of light source |
6500 h |
| Lamp type |
UHE |
| Lamp power |
230 W |
| Service life of light source (economic mode) |
17000 h |
| Lens system |
|---|
| Zoom ratio |
1:1.62 |
| Zoom capability |
Yes |
| Focus |
Manual |
| Focal length range |
18.2 - 29.1 mm |
| Aperture range (F-F) |
1.51 - 1.77 |
| Throw ratio |
1.3 - 2.09:1 |
| Zoom type |
Manual |
| Video |
|---|
| Analog signal format system |
Not supported |
| Full HD |
Yes |
| 3D |
No |
| Video colour modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB |
| Ports & interfaces |
|---|
| VGA (D-Sub) ports quantity |
2 |
| HDMI ports quantity |
1 |
| Composite video in |
1 |
| Microphone in |
Yes |
| Serial interface type |
RS-232C |
| DVI port |
No |
| AC (power) in |
Yes |
| Service port type |
USB Type-A |
| USB 2.0 Type-A ports quantity |
1 |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
10,100 Mbit/s |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Ethernet LAN (RJ-45) ports |
1 |
| Features |
|---|
| Interactive |
No |
| HDCP |
Yes |
| Password protection |
Yes |
| Noise level |
37 dB |
| Noise level (economic mode) |
28 dB |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| RMS rated power |
16 W |
| Design |
|---|
| Market positioning |
Presentation |
| Product colour |
White |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Placement |
Ceiling, Desktop |
| Display |
|---|
| Built-in display |
No |
| Power |
|---|
| AC input voltage |
100 - 240 V |
| AC input frequency |
50/60 Hz |
| Power source |
AC |
| Power consumption (typical) |
284 W |
| Power consumption (PowerSave) |
0.3 W |
| Power consumption (economy mode) |
181 W |
| Operational conditions |
|---|
| Storage temperature (T-T) |
-10 - 60 °C |
| Storage relative humidity (H-H) |
10 - 90% |
| Weight & dimensions |
|---|
| Width |
309 mm |
| Depth |
293 mm |
| Height |
105 mm |
| Weight |
3.1 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Batteries included |
Yes |
