3LCD, 3200Lm, 1920 x 1080, 16:9, 10000:1, 30 - 300", 10bits, NFC, Wireless LAN IEEE 802.11b/g/n, 39dB, 292 x 213 x 44mm, 1.8kg
Key Features
- 3 x brighter colours and reliable performance* – 3LCD, 3-Chip technology. Look for both high colour brightness and high white brightness
- Bright images – 3,200 lumens colour and 3,200 lumens white brightness
- Brilliant full HD performance – 1080p resolution (1920 x 1080) for sharp, widescreen images
- Wireless – project from your laptop, tablet, or smartphone without plugging into the projector, so you can move freely about the room
- Travel friendly – weighs just 1.83kg
- Fast, easy image adjustments – auto horizontal and vertical keystone correction, plus screen fit to quickly adjust the image to fit the screen, even if the projector is placed off centre
- Fast wireless setup for your mobile device – just scan the on-screen QR code using your phone or tablet
- Versatile connectivity – compatible with the latest laptops and media players — supports HDMI, Chromecast via HDMI® and MHL-enabled devices
Description
3LCD technology
All Epson projectors are based on 3-chip LCD technology for amazing colour, incredible detail and solid reliability. 3LCD's 3-chip architecture dedicates an entire chip to process each primary colour - red, green and blue, continuously. Unlike single-chip technology that delivers colour sequentially, you get full-time colour. The result is vibrant, realistic images and video all delivered with 3LCD's true-to-life colour.
3x brighter colours with Epson projectors
Brilliant image quality requires high colour brightness (colour light output), and Epson® 3LCD projectors have 3 x brighter colours than leading competitive projectors*.
One brightness measurement (lumens) is not enough. A projector's specification needs to show both high colour brightness and high white brightness. If colour brightness is lower than white brightness, images may be dark, dull and lose detail. If not provided, be sure to ask for a projector's colour brightness specification.
Brilliant high definition
With brightness up to 3,200 lumens the screen is easily viewed from anywhere in the room, even without dimming the lights. Even though its light weight and compact size enable it to be carried from room to room, the projector is capable of highly visible images thanks to its high brightness and superior 10,000:1 contrast ratio.
High brightness
With 3,200 lumens, the 1975F screen is easily viewed from anywhere in the room, even without dimming the lights. Even though its light weight and compact size enable it to be carried from room to room, the projector is capable of highly visible images thanks to its high brightness and superior 10,000:1 contrast ratio.
Enhanced connectivity with NFC
With the NFC function, the projector can be turned on automatically and connected wirelessly by simply touching an NFC compatible smartphone to the projector. Epson iProjection can also be connected automatically once the compatible smartphone has been connected. Conventional cumbersome wireless settings are no longer necessary.
Enhanced connectivity with iProjection
Wirelessly connect directly to laptops, tablets, smartphones or to a network for easy control over your presentations. This free application allows you to travel light and present from your mobile device. Just turn on the projector, use Epson iProjection to scan the on-screen QR code, and share content on the big screen.
Ultra-slim and lightweight design
The 1700 series is so compact it can fit into your briefcase along with your documents making it convenient to carry around with you.
Miracast
With Miracast support for screen mirroring, you can now project your smartphone or tablet screens without a cable connection. Receive easy wireless transmission of full HD (1080p) video and sound from your devices without the complicated set up. There's also no need to purchase any external wireless modules separately.
HDMI connectivity and MHL
Get both audio and brilliant HD video content with just one cable that can connect with the latest laptops, Blu-ray Disc®, media players and MHL-enabled devices. The 1700 series enables you to display content from MHL-enabled smartphones and tablets, as well as charge your MHL-enabled device when it’s connected to the projector.
Gesture presenter
With this function, you can present smarter without a laser pointer. Simply move your hand in front of the arrows and make your presentation more engaging and realistic with the audience.
Easy image adjustments with keystone adjustor
Position your projector almost anywhere in the room and still get a correctly proportioned image with auto vertical correction and easy-slide horizontal image correction. In cases where the image extends beyond the frame of the screen or whiteboard you just have to push the "Screen Fit" button and the image frame automatically matches up with the edges of the screen. 'Slide keystone adjuster' enables you to adjust the image easily and quickly, even in a limited space, making it perfect for narrow spaces, such as on a desk.
Quick, convenient control
The Epson 1700 series is easier to control than ever through its auto power on feature. There is no need to turn on the power using the remote control or the power button on the projector itself because startup is activated with cable insertion.
With sleep mode (A/V Mute) you can pause your presentation without turning the projector off. The 1700 series also enables you to quickly power down the projector, pack up and go with its Instant Off® feature, allowing you to control your projector with the flip of a switch.
Shorter throw distance
The short throw ratio means you can project onto a large screen even in small spaces eliminating concern about where presentations can be made.
New home screen
Get up and running in a snap with an intuitive, user-friendly home screen. Select the content source and easily access frequently-used functions such as keystone correction, volume control, Split Screen and more. Wireless connections can be made easily because all the information you need is right there on the screen.
Specifications
| Projector |
|---|
| Number of colours |
1.073 billion colours |
| Projector brightness |
3200 ANSI lumens |
| Projection technology |
3LCD |
| Projector native resolution |
1080p (1920x1080) |
| Screen size compatibility |
762 - 7620 mm (30 - 300") |
| Native aspect ratio |
16:9 |
| Projection distance (wide) |
0.7 - 6.8 m |
| Projection distance (tele) |
0.8 - 8.2 m |
| Contrast ratio (typical) |
10000:1 |
| Vertical scan range |
100 - 120 Hz |
| Projector brightness (economic mode) |
1900 ANSI lumens |
| Matrix size |
1.5 cm (0.59") |
| Keystone correction, vertical |
-30 - 30° |
| Keystone correction, horizontal |
-20 - 20° |
| Light source |
|---|
| Light source type |
Lamp |
| Service life of light source |
4000 h |
| Lamps quantity |
1 lamp(s) |
| Lamp power |
214 W |
| Service life of light source (economic mode) |
7000 h |
| Lens system |
|---|
| Zoom capability |
Yes |
| Focus |
Manual |
| Focal length range |
13.52 - 16.22 mm |
| Aperture range (F-F) |
1.58 - 1.7 |
| Throw ratio |
1.04 - 1.26:1 |
| Zoom type |
Manual |
| Video |
|---|
| Full HD |
Yes |
| 3D |
No |
| Video processing |
10 bit |
| Video colour modes |
Blackboard, Cinema, Dynamic, Presentation, sRGB |
| Supported video modes |
1080p |
| Supported graphics resolutions |
1920 x 1080 (HD 1080) |
| Ports & interfaces |
|---|
| Mobile High-Definition Link (MHL) |
Yes |
| VGA (D-Sub) ports quantity |
1 |
| HDMI ports quantity |
1 |
| USB 2.0 ports quantity |
2 |
| Composite video in |
1 |
| PC in (D-Sub) |
Yes |
| DVI port |
No |
| Network |
|---|
| Smart TV |
No |
| Ethernet LAN |
No |
| Wi-Fi |
Yes |
| Wi-Fi standards |
802.11b,802.11g,Wi-Fi 4 (802.11n) |
| Storage |
|---|
| Card reader integrated |
No |
| Features |
|---|
| Interactive |
No |
| HDCP |
Yes |
| Password protection |
Yes |
| Air filter |
Yes |
| Noise level |
39 dB |
| Noise level (economic mode) |
30 dB |
| Multimedia |
|---|
| Built-in speaker(s) |
Yes |
| Number of built-in speakers |
1 |
| RMS rated power |
1 W |
| Design |
|---|
| Market positioning |
Portable |
| Product type |
Standard throw projector |
| Product colour |
Black, White |
| Cable lock slot type |
Kensington |
| Cable lock slot |
Yes |
| Placement |
Desktop, Ceiling |
| Power |
|---|
| Power source |
AC |
| Power consumption (typical) |
295 W |
| Power consumption (standby) |
0.34 W |
| Power consumption (economy mode) |
208 W |
| Weight & dimensions |
|---|
| Width |
292 mm |
| Depth |
213 mm |
| Height |
44 mm |
| Weight |
1.8 kg |
| Packaging content |
|---|
| Remote control included |
Yes |
| Carrying case |
Yes |
| Cables included |
AC, VGA |
| Batteries included |
Yes |
| Technical details |
|---|
| Standard interfaces |
HDMI, NFC, USB, VGA, Wireless LAN |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
