2000 VA, 1800 W, 6 IEC C13 + 2 AU GPO
Key Features
- Li-Ion batteries for longer life
- On-line double conversion topology, with automatic by-pass and PFC system
- Energy Star UPS (up to 93.5% efficiency in Online mode)
- More real power in watts, Unity power factor (VA=W)
- 5 years full warranty
- Flexible RT form factor : convertible Tower / Rack
- Easy to operate : next-generation multilingual LCD display
- Manageable outlets groups (2 groups) with Energy metering
- 1 USB port + 1 Serial + 3 dry contacts (optocouplers on DB9)
- 1 Slot for optional com card (Network Management card, ModBus or Contacts/Serial cards)
- Monitoring & shutdown software for VMware, Hyper-V etc..
- Long backup time with up to 4 optional EBM cabinets, with automatic detection
- All necessary hardware for rack & tower mounting included
Description
Set-it-and-forget-it deploymentThe latest addition to Eaton's 9 series single-phase double-conversion UPS line, the Eaton 9PX 6kVA lithium-ion UPS offers a larger power rating, remote firmware upgrades, moving closer to a complete set-it-and-forget-it solution. Available in rackmount and tower form, the 9PX lithium-ion UPS has the same reliable features as the lead-acid UPS, including load segments that allow for prioritized shutdown, remote power on (RPO), remote on/off (ROO) and output relay ports that increase control capabilities.
Specifications
| Power |
|---|
| Output power capacity |
2 kVA |
| Output power |
1800 W |
| Input operation voltage (min) |
176 V |
| Input operation voltage (max) |
276 V |
| Output operation voltage (min) |
230 V |
| Output operation voltage (max) |
1 V |
| Surge energy rating |
296 J |
| Maximum current |
16 A |
| Efficiency |
94% |
| Power factor |
0.99 |
| Output voltage regulation |
1% |
| Crest factor |
3:1 |
| Input frequency |
40/70 Hz |
| Performance |
|---|
| UPS topology |
Double-conversion (Online) |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Waveform |
Sine |
| Noise level |
47 dB |
| Features |
|---|
| UPS topology |
Double-conversion (Online) |
| Output power capacity |
2 kVA |
| Number of output phases |
1 |
| Number of input phases |
1 |
| Output power |
1800 W |
| Input operation voltage (min) |
176 V |
| Input operation voltage (max) |
276 V |
| Output operation voltage (min) |
230 V |
| Output operation voltage (max) |
1 V |
| Surge energy rating |
296 J |
| Maximum current |
16 A |
| Efficiency |
94% |
| Waveform |
Sine |
| Power factor |
0.99 |
| Output voltage regulation |
1% |
| Crest factor |
3:1 |
| Noise level |
47 dB |
| Input frequency |
40/70 Hz |
| Ports & interfaces |
|---|
| AC outlets quantity |
6 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Battery |
|---|
| Battery technology |
Lithium |
| Design |
|---|
| Form factor |
Rackmount/Tower |
| Product colour |
Black |
| Certification |
IEC/EN 62040-1, IEC/EN 62040-2 Cat C1, IEC/EN 62040-3, UL 1778, CSA 22.2, CISPR22 Class B, FCC part 15 Class B, CE, CB, EAC |
| Cooling type |
Active |
| Built-in fan |
Yes |
| Control type |
Buttons |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-25 - 55 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 1500 m |
| Non-operating altitude |
1500 - 3000 m |
| Certificates |
|---|
| Certification |
IEC/EN 62040-1, IEC/EN 62040-2 Cat C1, IEC/EN 62040-3, UL 1778, CSA 22.2, CISPR22 Class B, FCC part 15 Class B, CE, CB, EAC |
| Cooling |
|---|
| Cooling type |
Active |
| Built-in fan |
Yes |
| Weight & dimensions |
|---|
| Width |
440 mm |
| Depth |
605 mm |
| Height |
86.5 mm |
| Weight |
22.1 kg |
