D-Link DGS-F1210-18PS-E network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

18 port Smart Managed Gigabit PoE Switch with 16 PoE+ ports (8 Long Reach 250m) and 2 SFP ports

Description

The D-Link DGS-F1210 Series Smart Managed Switches are the latest generation of switches to provide increased Power over Ethernet (PoE) output, a range of physical interface types, multiple management interfaces, and advanced Layer 2 features. With all of these features combined, the DGS-F1210 Series provide a cost-efficient and flexible solution for expanding any business network.

PoE Support
The DGS-F1210 Series switches provide Power over Ethernet (PoE) support, reducing deployment time for IP cameras, VoIP phones, and access points. Dedicated power adapters are no longer required, as the DGS-F1210 Series switches comply with IEEE 802.3af (PoE) and 802.3at (PoE+) standards and provide up to 30 watts per port. The DGS-F1210-26MPS-E model offers extended PoE budget of up to 380 Watts. Additionally, 8 PoE ports in each switch offer Long Reach PoE technology1, allowing the use of longer network cable runs which are normally limited to 100m. The Long Reach PoE technology supports cables up to 250m long.

Seamless Integration
The DGS-F1210 Series support a range of port and media types, including 10/100/1000BASE-T RJ-45 ports, PoE and PoE+ and Gigabit SFP ports. The DGS-F1210-10PS-E, DGS-F1210-18PS-E, DGS-F1210-26PS-E and DGS-F1210-26MPS-E models feature 2 SFP ports allowing you to choose the most suitable media type for your requirements. All DGS-F1210 Series switches include support for IEEE 802.3af/at and high power budgets, allowing more PoE devices to be powered by the switch and for devices to be installed in remote locations without immediate access to power outlets.

The DGS-F1210 Series come equipped with a complete line-up of Layer 2 features, including IGMP snooping, port mirroring, Spanning Tree Protocol (STP), and Link Aggregation Control Protocol (LACP). The IEEE 802.3x Flow Control function allows servers to directly connect to the switch for
fast, reliable data transfers. The DGS-F1210 Series also support advanced features such as port segmentation, which allow network administrators to divide the network into VLANs, increasing network efficiency. Network maintenance features include loop detection and cable diagnostics.
Loop detection significantly speeds up troubleshooting by automatically detecting and shutting down switching loops. The cable diagnostics feature, designed primarily for administrators and customer service representatives, determines the cable quality and quickly discovers errors, allowing for hassle-free diagnostics and maintenance.

The DGS-F1210 Series support 802.1X port-based authentication, allowing the clients to be authenticated through external RADIUS servers. The Access Control List (ACL) feature helps to enhance network security and helps to protect the internal IT network. The DGS-F1210 Series also
feature Address Resolution Protocol (ARP) spoofing prevention, which helps to provide protection from attacks on the network that could allow an intruder to sniff data frames, modify traffic, or bring traffic to a halt altogether by sending fake ARP messages. To help prevent ARP spoofing attacks, the switch uses packet control ACLs to block invalid packets that contain fake ARP messages. The DHCP Snooping feature filters DHCP replies on unauthorised ports to prevent them from being assigned an IP address.

Specifications

Management features
Traffic classification	Yes
ARP inspection	Yes
Switch layer	L2
Switch type	Managed
Web-based management	Yes
System event log	Yes
Quality of Service (QoS) support	Yes
Multicast support	Yes
Configuring Location Settings (CLI)	Yes
Ports & interfaces
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports quantity	16
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Console port	RJ-45
Power connector	AC-in jack
Network
Cable types supported	Cat5e
MAC address auto-learning supported	Yes
MAC address auto-aging supported	Yes
Active link detection	Yes
Networking standards	IEEE 802.1D, IEEE 802.1Q, IEEE 802.1af, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3at, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Number of VLANs	4000
VLAN support	Yes
Spanning tree protocol	Yes
Rate limiting	Yes
Port mirroring	Yes
Link aggregation	Yes
Flow control support	Yes
Ethernet LAN data rates	10,100,1000 Mbit/s
10G support	No
Auto-negotiation	Yes
IGMP snooping	Yes
Data transmission
Jumbo frames	10000
MAC address table	8000 entries
Switching capacity	36 Gbit/s
Number of queues	8
Jumbo frames support	Yes
Forwarding rate	23.8 Mpps
Number of VLANs	4000
Security
Loop protection	Yes
IP-MAC-Port binding	Yes
BPDU filtering/protection	Yes
Authentication	Port-based authentication
SSH/SSL support	Yes
Security algorithms	HTTPS, SSH
IGMP snooping	Yes
Password protection	Yes
Authentication type	IEEE 802.1x
Queue scheduling algorithms	SP, WFQ, Weighted Round Robin (WRR)
MAC address entries	Dynamic MAC address entries, Static MAC address entries
DHCP features	DHCP snooping
Multicast features
Multicast support	Yes
Multicast features	Interface-based multicast traffic statistics
Protocols
Supported network protocols	IPv4, IPv6
Design
Rack mounting	Yes
Product colour	Grey
LED indicators	PoE, Power, System
Number of fans	1 fan(s)
Performance
Noise level	35 dB
Auto-negotiation	Yes
Power
Power consumption (max)	150 W
Power supply included	Yes
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	15 W
Number of power supply units	1
Power source	AC
Power connector	AC-in jack
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port	30 W
Power over Ethernet (PoE)	Yes
Power over Ethernet plus (PoE+) ports quantity	16
Total Power over Ethernet (PoE) budget	135 W
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	10 - 95%
Virtual LAN features
Number of VLANs	4000
VLAN support	Yes
Weight & dimensions
Width	440 mm
Depth	180 mm
Height	44 mm
Weight	2.9 kg
Other features
Ethernet LAN data rates	10,100,1000 Mbit/s
