600 VA, 360 W, IEC C13 x 6, Line-interactive, Sine Wave, AVR, Hot-swap, 1U Rack, Silver
Key Features
- Line-interactive UPS Topology
- Energy Saving Technology
- Simulated Sine Wave Output
- Automatic Voltage Regulation (AVR)
- Overload Protection
- Hot-swappable Batteries
- Surge and Spike Protection
- EMI and RFI Filtration
- Phone/Fax/Modem/DSL/Network Protection
- LCD Status Display
- USB Connectivity Port
- PowerPanel® Management Software
- SNMP/HTTP Remote Management Capability (Optional)
- Rack Mount Form Factor
Description
CyberPower OR600ERM1U Line-Interactive UPS offers Simulated Sine Wave output power for office system devices including PCs, workstations, networking devices, and peripherals. It’s typically integrated in the back office, server room, and data center environment to ensure a reliable backup power supply during power failures. In addition, the rackmount / tower convertible design gives it enhanced flexibility for installation and operation in almost any environment.
The UPS has a multifunction LCD display which offers real-time information, including input and output voltage levels, load and battery levels, battery runtime, overload warning, and a silent mode. With the network ports on the UPS, it prevents network devices from being subjected to sudden power surges caused by lightning, thereby avoiding potential system damage. As for battery maintenance, the UPS allows battery hot-swapping, which enables users to perform normal battery maintenance without significant interruption.
Specifications
| Power |
|---|
| Output frequency |
50/60 Hz |
| Output power capacity |
0.6 kVA |
| Output power |
360 W |
| Input operation voltage (min) |
165 V |
| Input operation voltage (max) |
271 V |
| Output operation voltage (min) |
230 V |
| Output operation voltage (max) |
230 V |
| Surge energy rating |
405 J |
| Maximum current |
10 A |
| Power factor |
0.6 |
| Input frequency |
50/60 Hz |
| Ports & interfaces |
|---|
| Cable length |
1.83 m |
| USB port |
Yes |
| AC outlets quantity |
6 AC outlet(s) |
| AC outlet types |
C13 coupler |
| Power plug |
C14 coupler |
| Serial ports quantity |
1 |
| Modem (RJ-11) ports |
1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Performance |
|---|
| Audible alarm modes |
Low battery alarm, Overload alarm |
| UPS topology |
Line-Interactive |
| Response time |
4 ms |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Surge protection features |
Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
| Waveform |
Sine |
| Power protection features |
Overload |
| Automatic Voltage Regulation (AVR) |
Yes |
| LED indicators |
Operation |
| Audible alarm(s) |
Yes |
| Features |
|---|
| Output frequency |
50/60 Hz |
| Country of origin |
China |
| Audible alarm modes |
Low battery alarm, Overload alarm |
| UPS topology |
Line-Interactive |
| Output power capacity |
0.6 kVA |
| Response time |
4 ms |
| Output power |
360 W |
| Input operation voltage (min) |
165 V |
| Input operation voltage (max) |
271 V |
| Output operation voltage (min) |
230 V |
| Output operation voltage (max) |
230 V |
| Surge energy rating |
405 J |
| Maximum current |
10 A |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Surge protection features |
Digital Subscriber Line (DSL), Fax, Modem, Network, Telephone |
| Waveform |
Sine |
| Power protection features |
Overload |
| Power factor |
0.6 |
| Automatic Voltage Regulation (AVR) |
Yes |
| Audible alarm(s) |
Yes |
| Input frequency |
50/60 Hz |
| Battery |
|---|
| Battery technology |
Sealed Lead Acid (VRLA) |
| Number of batteries supported |
1 |
| Battery recharge time |
8 h |
| Typical backup time at half load |
13 min |
| Typical backup time at full load |
4 min |
| Hot-swap battery |
Yes |
| Design |
|---|
| Country of origin |
China |
| Rack capacity |
1U |
| Form factor |
Rackmount |
| Product colour |
Silver |
| Certification |
CE, EAC, RCM |
| Cable length |
1.83 m |
| LED indicators |
Operation |
| Housing material |
Metal |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-15 - 45 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 3000 m |
| Non-operating altitude |
0 - 15000 m |
| Technical details |
|---|
| Output frequency |
50/60 Hz |
| Harmonized System (HS) code |
8504408590 |
| Compliance certificates |
RoHS |
| Certificates |
|---|
| Certification |
CE, EAC, RCM |
| Compliance certificates |
RoHS |
| Packaging content |
|---|
| Cables included |
USB cable |
| Weight & dimensions |
|---|
| Width |
433 mm |
| Depth |
235 mm |
| Height |
44 mm |
| Weight |
7.8 kg |
| Package width |
530 mm |
| Package depth |
315 mm |
| Package height |
155 mm |
| Package weight |
10.3 kg |
| Packaging data |
|---|
| Cables included |
USB cable |
| Package width |
530 mm |
| Package depth |
315 mm |
| Package height |
155 mm |
| Package weight |
10.3 kg |
| Logistics data |
|---|
| Country of origin |
China |
| Harmonized System (HS) code |
8504408590 |
