Online Double Conversion USV 3000VA/2700WTower, ECO Mode, LCD, USB, Smart-Slot
Key Features
- Online (Double Conversion) UPS Topology
- Generator Compatible
- Zero Transfer Time
- Extended Battery Module (EBM)
- EMI and RFI Filtration
- Relay-type Dry Contact
- Variable Speed Fans
- PowerPanel Cloud Service
- ECO Mode
- Overload Protection
- Smart Battery Management (SBM)
- Surge and Spike Protection
- Color LCD Panel
- PowerPanel Management Software
- SNMP/HTTP Remote Management Capability (Optional)
- Sleek and Stylish Design
Description
CyberPower OLS3KECR provides reliable battery backup and power protection for multimedia devices, IT equipment, computers, workstations, NAS/Storage devices, telecom devices, networking devices, security/emergency systems, and surveillance systems. The UPS adopts double-conversion topology to provide optimal power quality as well as ECO Mode to conserve power and save on energy costs. Furthermore, the product is generator compatible to achieve power continuity and designed with Smart Battery Management (SBM) to extend battery lifespan.
In order to reduce noise and ensure greater comfort for users, the UPS is equipped with variable speed fans to provide automatic thermal management based on power load. The color LCD panel displays intuitive and clear system information, allowing users to monitor and configure settings easily. The product can be used with PowerPanel Management Software to achieve real-time monitoring and remote management of the UPS.
Specifications
| Power |
|---|
| Output frequency |
50/60 Hz |
| Output power capacity |
3 kVA |
| Output power |
2700 W |
| Input operation voltage (min) |
80 V |
| Input operation voltage (max) |
300 V |
| Output operation voltage (min) |
208 V |
| Output operation voltage (max) |
240 V |
| Surge energy rating |
590 J |
| Maximum current |
13.04 A |
| Emergency Power Off (EPO) |
Yes |
| Output voltage Total Harmonic Distortion (THD) |
5% |
| Output voltage regulation |
1% |
| Output power factor |
0.9 |
| Input power factor |
0.99 |
| Crest factor |
3:1 |
| Efficiency (ECO mode) |
97% |
| ECO mode |
Yes |
| Input frequency |
50/60 Hz |
| Ports & interfaces |
|---|
| Cable length |
1.5 m |
| Socket circuit breaker |
Yes |
| Emergency Power Off (EPO) connector |
Yes |
| USB port |
Yes |
| AC outlets quantity |
7 AC outlet(s) |
| AC outlet types |
Type F, C13 coupler, Terminal |
| Power plug |
Type F |
| RS-232 ports |
1 |
| USB port type |
USB Type-B |
| Performance |
|---|
| Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm, Fault, Battery replacement |
| UPS topology |
Double-conversion (Online) |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Waveform |
Pure sine |
| Power protection features |
Input fuse, Overload |
| Automatic Voltage Regulation (AVR) |
Yes |
| Audible alarm(s) |
Yes |
| Overload capacity (1 minute) |
120% |
| Overload capacity (10 seconds) |
120% |
| Features |
|---|
| Output frequency |
50/60 Hz |
| Audible alarm modes |
Alarm when on battery, Low battery alarm, Overload alarm, Fault, Battery replacement |
| UPS topology |
Double-conversion (Online) |
| Output power capacity |
3 kVA |
| Output power |
2700 W |
| Input operation voltage (min) |
80 V |
| Input operation voltage (max) |
300 V |
| Output operation voltage (min) |
208 V |
| Output operation voltage (max) |
240 V |
| Surge energy rating |
590 J |
| Maximum current |
13.04 A |
| EMI/RFI noise filtering |
Yes |
| Surge protection |
Yes |
| Emergency Power Off (EPO) |
Yes |
| Waveform |
Pure sine |
| Power protection features |
Input fuse, Overload |
| Output voltage Total Harmonic Distortion (THD) |
5% |
| Output voltage regulation |
1% |
| Output power factor |
0.9 |
| Input power factor |
0.99 |
| Crest factor |
3:1 |
| Automatic Voltage Regulation (AVR) |
Yes |
| Audible alarm(s) |
Yes |
| Overload capacity (1 minute) |
120% |
| Socket circuit breaker |
Yes |
| Overload capacity (10 seconds) |
120% |
| Efficiency (ECO mode) |
97% |
| ECO mode |
Yes |
| Input frequency |
50/60 Hz |
| Heat dissipation |
1139 BTU/h |
| Battery |
|---|
| Battery technology |
Sealed Lead Acid (VRLA) |
| Number of batteries supported |
6 |
| Battery recharge time |
4 h |
| Typical backup time at half load |
12.7 min |
| Typical backup time at full load |
3 min |
| Battery voltage |
12 V |
| Battery capacity |
9 Ah |
| Replacement battery cartridge |
BPS72V40AC |
| Design |
|---|
| Form factor |
Tower |
| Product colour |
Black |
| Cable length |
1.5 m |
| Housing material |
Metal |
| Display type |
LCD |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
0 - 95% |
| Storage relative humidity (H-H) |
0 - 95% |
| Operating altitude |
0 - 1500 m |
| Non-operating altitude |
0 - 1500 m |
| Technical details |
|---|
| Output frequency |
50/60 Hz |
| Bypass |
GreenPower UPS |
| Compliance certificates |
CE, EAC, UKCA, RoHS |
| Certificates |
|---|
| Compliance certificates |
CE, EAC, UKCA, RoHS |
| Packaging content |
|---|
| Cables included |
USB cable |
| Manual |
Yes |
| Weight & dimensions |
|---|
| Width |
155 mm |
| Depth |
341 mm |
| Height |
400 mm |
| Weight |
25 kg |
| Packaging data |
|---|
| Cables included |
USB cable |
| Manual |
Yes |
| Other features |
|---|
| Bypass |
GreenPower UPS |
