Cisco Meraki MS130-24X network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U White
SAVE 59%

Cisco

Cisco Meraki MS130-24X network switch Managed L2 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) 1U White

SKU: MS130-24X
Your price $5,745.00
List price $13,889.37 Save $8,144.37
GST included · AUD

In stock — ready to ship

Estimate shipping

Enter an Australian postcode for a quick estimate.

Final shipping options and price are confirmed at checkout.

  • Local Australian stock - Brand NEW
  • Australian manufacturer warranty
  • GST included
  • Secure checkout

Need bulk pricing for schools or councils? Request a quote via Contact Us.

L2, 18 - 10/100/1000 Mbps, RJ45, 802.3bt, PoE up to 30W per port, 4x 10 Gbe SFP+, DHCP Snooping, 802.1X Authentication, IPv4/6 ACL, SNMP/Syslog, 100 - 240 V, 12-6A, 50 - 60 Hz, 4.4 x 44 x 25 cm, 4.25 kg

Key Features

  • Managed via Cisco Meraki Dashboard
  • Remote Packet Capture Tools via Meraki Dashboard
  • Automatic Firmware upgrades
  • SNMP/Syslog Integration
  • IPv4/6 ACL support
  • 802.1Q VLAN tagging
  • DHCP Snooping
  • 802.1X Authentication
  • 10/100/1000 Mbps RJ45
  • 100M/1G/2.5G mGbE RJ45
  • 4x 10 Gbe SFP+ models available
  • 802.3bt PoE up to 30W per port

Description

Powerful full-size switch with optional PoE+ and mGig
High-performance switch optimized for medium to large campuses with Wi-Fi and IoT deployments.

Cisco Meraki MS130 switches provide Layer 2 access switching, ideal for branch and campus deployments. The MS130 series features a variety of options designed to meet the diverse needs of branch and campus deployments.

With 10 different models, capable of providing up to 740W of power over a variety of port densities, including SFP+ capable uplinks, the MS130 line is fully ready to support future wireless infrastructure deployments across a variety of different environments.

Specifications

Management features
Switch layer L2
Switch type Managed
Quality of Service (QoS) support Yes
Multicast support Yes
Cloud-managed Yes
Ports & interfaces
SFP+ module slots quantity 4
Basic switching RJ-45 Ethernet ports quantity 18
Basic switching RJ-45 Ethernet ports type Gigabit Ethernet (10/100/1000)
2.5G Ethernet (copper) ports quantity 6
Number of management ports 1 pc(s)
Network
Networking standards IEEE 802.1x, IEEE 802.3bt
Spanning tree protocol Yes
Port mirroring Yes
Link aggregation Yes
10G support No
Virtual LAN features Voice VLAN
IGMP snooping Yes
Data transmission
Switching capacity 146 Gbit/s
Security
Authentication MAC-based authentication
Security algorithms SNMP
IGMP snooping Yes
Authentication type RADIUS
DHCP features DHCP snooping
Multicast features
Multicast support Yes
Multicast features Multicast traffic suppression
Protocols
IPv4 & IPv6 features IPv4/IPv6 access-control list (ACL)
Design
Rack mounting Yes
Product colour White
Form factor 1U
LED indicators Yes
Performance
Firmware upgradeable Yes
Mean time between failures (MTBF) 309196 h
Power
Power consumption (max) 421 W
Power supply included Yes
AC input voltage 100 - 240 V
AC input frequency 50/60 Hz
Input current 12 A
Power source AC
Power over Ethernet (PoE)
Power over Ethernet (PoE) power per port 30 W
Power over Ethernet (PoE) Yes
Total Power over Ethernet (PoE) budget 370 W
Operational conditions
Operating temperature (T-T) 0 - 45 °C
Storage temperature (T-T) -20 - 70 °C
Operating relative humidity (H-H) 5 - 95%
Virtual LAN features
Virtual LAN features Voice VLAN
Weight & dimensions
Width 440 mm
Depth 250 mm
Height 44 mm
Weight 4.25 kg
IPv4 & IPv6 features
IPv4 & IPv6 features IPv4/IPv6 access-control list (ACL)
Brand
Cisco
SKU
MS130-24X
