Aironet Dual-Band Omnidirectional Wi-Fi Antenna, 6 dBi (2.4 GHz)/8 dBi (5 GHz), N-Type Male Connector, Direct Mount, 1-Year Limited Hardware Warranty (AIR-ANT2568VG-N=)
Key Features
- OMNIDIRECTIONAL WI-FI ANTENNA: 6 dBi (2.4 GHz)/8 dBi (5 GHz); grey radome; suitable for use on Aironet outdoor access points
- CONNECTION AND MOUNT: Direct mount on access point; no cable attachments
- 360-DEGREE RADIATION PATTERN: Intended for deployment when coverage in all directions from the antenna is required
- PERFORMANCE: Designed for improved coverage
- PEACE OF MIND: 1-year limited hardware warranty
Description
The Cisco Aironet AIR-ANT2568VG-N= Dual-Band Omnidirectional Wi-Fi Antenna is designed with improved coverage and performance in mind. This FCC-approved omnidirectional antenna provides a 360-degree radiation pattern and is intended for deployment when coverage in all directions from the antenna is required.
Specifications
| Performance |
|---|
| Antenna gain level (max) |
8 dBi |
| Frequency band |
2400 - 2483, 5150 - 5925 GHz |
| Impedance |
50 Ω |
| Antenna gain (5 GHz) |
8 dBi |
| Antenna gain (2.4 GHz) |
6 dBi |
| Features |
|---|
| Country of origin |
China |
| International Protection (IP) code |
IP67 |
| Antenna gain level (max) |
8 dBi |
| Frequency band |
2400 - 2483, 5150 - 5925 GHz |
| Antenna type |
Omni-directional antenna |
| Polarization |
Vertical polarization |
| Impedance |
50 Ω |
| Antenna gain (5 GHz) |
8 dBi |
| Antenna gain (2.4 GHz) |
6 dBi |
| Antenna connector type |
N-type |
| Technical details |
|---|
| Harmonized System (HS) code |
85177100 |
| Operational conditions |
|---|
| Operating temperature (T-T) |
-30 - 70 °C |
| Storage temperature (T-T) |
-40 - 85 °C |
| Weight & dimensions |
|---|
| Package width |
152.4 mm |
| Package depth |
482.6 mm |
| Package height |
50.8 mm |
| Package weight |
362.81 g |
| Weight |
204.1 g |
| Height |
377 mm |
| Diameter |
3.81 cm |
| Packaging content |
|---|
| Quantity per pack |
1 pc(s) |
| Packaging content |
AIR-ANT2568VG-N Antenna |
| Logistics data |
|---|
| Quantity per pack |
1 pc(s) |
| Harmonized System (HS) code |
85177100 |
