ATEN VE801-AT-U AV extender AV transmitter & receiver Black

HDMI Extender (T+R) over 1 CAT5e/6 Cable (70m) ,4K / HDBaseT-Lite (Class B)

Key Features

• Extends HDMI signals over a single Cat 5e/6/6a cable or ATEN 2L-2910 Cat 6 cable
• HDMI (3D, Deep color, 4K); HDCP 2.2 compliant
• Superior video quality – up to 4K@35m (Cat 5e/6) / 40m (Cat 6a or ATEN 2L-2910 Cat 6 cable)
• HDBaseT Anti-jamming – resists signal interference during high-quality video transmission using HDBaseT technology
• Plug-and-play
• Rack-mountable

Description

The VE801 HDMI HDBaseT-Lite Extender extends an HDMI signal up to 70m from the HDBaseT source using one Cat 5e/6/6a cable. It supports HDMI features that include 3D, Deep Color and 4K image resolutions, plus Dolby Digital 5.1, DTS HD audio and it is HDCP compatible. The VE801 all-in-one design provides an easy method for mounting the device in any location. The side panel provides slip-resistant grooves that help prevent accidental drops when installing the unit. The grooves also enhance the ability to see the LED status lights. The VE801 is perfect for digital entertainment centers or any installation that requires superior HDMI video quality to be extended for great distances.
1x VE801T/R HDMI HDBaseT-Lite Extender
2x 0AD6-1F05-26EG Power Adapters
1x User Instructions

Specifications

Features
Material	Metal
HDCP	Yes
Type	AV transmitter & receiver
Maximum resolution	3840 x 2160 pixels
Cable types supported	Cat5, Cat6, Cat6a
Maximum transfer distance	70 m
Supported video modes	1080p
LED indicators	Yes
Bandwidth	340 MHz
Product colour	Black
Ports & interfaces
RJ-45 input ports	1
RJ-45 output ports	1
HDMI in	1
Number of HDMI outputs	1
Ethernet LAN	Yes
DC-in jack	Yes
Connectivity technology	Wired
Operational conditions
Operating relative humidity (H-H)	0 - 80%
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Weight & dimensions
Receiver dimensions (WxDxH)	34.3 x 98.6 x 30 mm
Receiver weight	250 g
Transmitter dimensions (WxDxH)	34.3 x 98.6 x 30 mm
Transmitter weight	240 g
Packaging data
Quantity per pack	2 pc(s)
Packaging content
AC adapter included	Yes
Technical details
Compliance certificates	RoHS
