ATEN 4-Port USB 4K HDMI KVMP™ Switch

4-Port USB 4K HDMI KVMP™ Switch (Cables included)

Key Features

• Superior video quality – up to 4096 x 2160 @ 60 Hz
• Supports Video DynaSync™
• All HDMI & USB cables included
• Computer selection via remote port selector, hotkeys, and USB mouse

Description

The CS784H is a 4-port desktop KVM switch designed for those who demand a streamlined workflow and uncompromising visual quality across multiple systems. It enables fast, reliable switching between four HDMI computers with up to 4K DCI resolution, while sharing a single keyboard, monitor, mouse, audio output, and USB peripherals through one KVM console. With multiple switching methods – including pushbuttons, hotkeys, and a remote port selector – the CS784H is the perfect companion for desktop setups in offices, content creation, remote work, design, and more.

Space-Efficient Desktop Setup
The CS784H simplifies control of up to four HDMI computer systems by sharing a single keyboard, monitor, and mouse from one KVM console, delivering a clutter-free and organized desktop workspace.

Superior Visual Clarity
The KVM switch is designed to deliver exceptional visual performance, supporting 1080p@60, 4K@60, and up to 5120×1440@60.

USB Peripheral Sharing
Media and data sharing between computers is fast and effortless via plug-n-play connection (e.g. hard drive, flash drive, printer, etc) to the USB ports on the KVM switch.

Flexible Port Selection
Port switching is quick and flexible via pushbuttons, hotkeys, or the remote port selector – whichever best fits your workflow.

All Essentials Packed. No Extras Needed.
Everything you need is included – 4 HDMI cables, 2 USB 2.0 A to B cables, 1 power adapter, and 1 remote port selector (wired switch button) – for instant setup.

Applications
The CS784H enables centralized control of up to 4 HDMI computers via one keyboard, mouse, and monitor, delivering a tidy and efficient desktop workspace where multitasking is streamlined and cable clutter is minimized.

Specifications

Ports & interfaces
Console USB ports quantity	2
Console ports	3.5mm headphone, HDMI, USB A
Number of computers controlled	4
Keyboard port type	USB
Mouse port type	USB
Video port type	HDMI
Audio connections	Yes
HDMI ports quantity	4
USB hub	Yes
USB 2.0 Type-B ports quantity	4
USB 2.0 Type-A hub ports quantity	2
Console HDMI ports quantity	1
Performance
HD type	4K Ultra HD
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Scan interval	1,99 s
Design
Product colour	Black
Push button	Yes
LED indicators	Yes
Housing material	Metal, Plastic
Country of origin	Thailand
Display
Built-in display	No
Power
Power source	DC
Power consumption (typical)	1.73 W
Video
HD type	4K Ultra HD
Video bandwidth	60 Hz
Maximum resolution	4096 x 2160 pixels
Technical details
USB hub	Yes
Features
Country of origin	Thailand
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	0 - 80%
Weight & dimensions
Width	81.7 mm
Depth	202.3 mm
Height	25 mm
Weight	470 g
Package width	100 mm
Package depth	283 mm
Package height	173 mm
Package weight	1.52 kg
Packaging data
Package width	100 mm
Package depth	283 mm
Package height	173 mm
Package weight	1.52 kg
Other features
Push button	Yes
Logistics data
Country of origin	Thailand
Master (outer) case width	292 mm
Master (outer) case length	517 mm
Master (outer) case height	194 mm
Master (outer) case gross weight	8.3 kg
