230V 50/60Hz, 3000VA/3000W, 9Ah
Key Features
- True double-conversion – Output power factor is 1 (maxium), which means all of the power supplied is being used for productive work and makes work the most efficient
- Programmable power management outlets – Users can easily and independently control load segments. During power failure, this feature enables users to extend battery time to mission-critical devices by shutting down noncritical devices
- Emergency Power Off function (EPO) – EPO connector at rear panel allows emergency UPS Power Off from a remote location
- SNMP + USB + RS-232 multiple communications – Allows either USB or RS-232 communication ports to work with SNMP interface simultaneously
Description
The ATEN Professional Online UPS is an exceptional and innovative electrical apparatus that provides emergency power to a load when the input power source, or the mains, fails. The basic technology of an online UPS is the same as in a standby or line-interactive UPS, however, the ATEN Professional Online UPS provides a much greater current of AC-to-DC battery-charger/rectifier where the rectifier and inverter are designed to run continuously with improved cooling systems.
1x Online UPS
1x Rack Mounting Kit
1x Rail Slide Kit
1x RS-232 Cable
1x USB Type A to B Cable
4x Power Cables
1x Tower Stand set
1x User Instructions
Specifications
| Power |
|---|
| Output power capacity |
3 kVA |
| Output power |
3000 W |
| Input operation voltage (min) |
110 V |
| Input operation voltage (max) |
300 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Efficiency |
90% |
| Crest factor |
3:1 |
| Charging current |
2 A |
| Efficiency (ECO mode) |
96% |
| ECO mode |
Yes |
| Input frequency |
40/70 Hz |
| Performance |
|---|
| UPS topology |
Double-conversion (Online) |
| Response time |
4 ms |
| Waveform |
Sine |
| Noise level |
50 dB |
| LED indicators |
Yes |
| Features |
|---|
| UPS topology |
Double-conversion (Online) |
| Output power capacity |
3 kVA |
| Response time |
4 ms |
| Output power |
3000 W |
| Input operation voltage (min) |
110 V |
| Input operation voltage (max) |
300 V |
| Output operation voltage (min) |
220 V |
| Output operation voltage (max) |
240 V |
| Efficiency |
90% |
| Waveform |
Sine |
| Crest factor |
3:1 |
| Noise level |
50 dB |
| Efficiency (ECO mode) |
96% |
| ECO mode |
Yes |
| Input frequency |
40/70 Hz |
| Charging current |
2 A |
| Ports & interfaces |
|---|
| USB port |
Yes |
| Serial interface |
Yes |
| Serial interface type |
RS-232 |
| AC outlets quantity |
9 AC outlet(s) |
| AC outlet types |
C13 coupler, C19 coupler |
| Power plug |
C20 coupler |
| USB 2.0 ports quantity |
1 |
| Serial ports quantity |
1 |
| RS-232 ports |
1 |
| Ethernet LAN (RJ-45) ports |
2 |
| USB port type |
USB Type-B |
| Battery |
|---|
| Battery technology |
Sealed Lead Acid (VRLA) |
| Number of batteries supported |
6 |
| Number of battery cells |
6 |
| Battery recharge time |
3 h |
| Typical backup time at half load |
10.1 min |
| Typical backup time at full load |
2.96 min |
| Cold start |
Yes |
| Battery voltage |
72 V |
| Battery capacity |
9 Ah |
| Charging current |
2 A |
| Design |
|---|
| Rack capacity |
2U |
| Form factor |
Rackmount/Tower |
| Product colour |
Black |
| Certification |
CE
RoHS |
| Cooling type |
Active |
| LED indicators |
Yes |
| Built-in fan |
Yes |
| Operational conditions |
|---|
| Operating temperature (T-T) |
0 - 40 °C |
| Storage temperature (T-T) |
-20 - 50 °C |
| Operating relative humidity (H-H) |
20 - 90% |
| Storage relative humidity (H-H) |
10 - 95% |
| Technical details |
|---|
| Harmonized System (HS) code |
85078000 |
| Cooling |
|---|
| Cooling type |
Active |
| Built-in fan |
Yes |
| Weight & dimensions |
|---|
| Width |
438 mm |
| Depth |
88 mm |
| Height |
630 mm |
| Weight |
27.6 kg |
| Package width |
88 mm |
| Package depth |
438 mm |
| Package height |
630 mm |
| Package weight |
34.8 kg |
| Packaging data |
|---|
| Cables included |
Output power cable, Power load cable, RS-232, USB cable |
| Manual |
Yes |
| Package width |
88 mm |
| Package depth |
438 mm |
| Package height |
630 mm |
| Package weight |
34.8 kg |
| Logistics data |
|---|
| Products per master (outer) case |
1 pc(s) |
| Master (outer) case width |
600 mm |
| Master (outer) case length |
760 mm |
| Master (outer) case height |
240 mm |
| Master (outer) case gross weight |
34.8 kg |
| Master (outer) case net weight |
27.6 kg |
| Harmonized System (HS) code |
85078000 |
| Certificates |
|---|
| Certification |
CE
RoHS |
| Packaging content |
|---|
| Cables included |
Output power cable, Power load cable, RS-232, USB cable |
| Manual |
Yes |
