ATEN 2-port USB 3.0 Peripheral Sharing Device

ATEN

ATEN 2-port USB 3.0 Peripheral Sharing Device

Read reviews
SKU: US234-AT
Your price $104.50
GST included · AUD
New Sealed in box Australian stock Warehouses in Sydney, Melbourne, Brisbane, Adelaide and Perth Delivery only - Pickup unavailable 2-5 Business days metro delivery. Australian manufacturer Warranty

In stock — ready to ship

Estimate shipping

Enter an Australian postcode for a quick estimate.

Final shipping options and price are confirmed at checkout.

Need bulk pricing for schools or councils? Request a quote via Contact Us.

2-port USB 3.0 Peripheral Sharing Device

Key Features

  • Enables 2 computers to share 4 USB 3.2 Gen1 devices
  • Simple port selection via remote port selector for convenient switch placement
  • USB 3.2 Gen1 compliant, supporting data transfer rates of up to 5 Gbps
  • LEDs indicates which computer is active
  • Over-current protection
  • Multiplatform support – Windows, Linux and Mac
  • Bus-powered
  • Micro USB power jack for additional power supply
  • Hot pluggable, no driver or software required

Description

ATEN US234 is a 2-port USB 3.2 Gen1 peripheral sharing device that allows users to share four USB devices between 2 different computers. US234 is USB 3.2 Gen1 compliant, which can support data transfer rate up to 5Gbps and backwards compatible with USB 2.0 and USB1.1. It is perfect for high-bandwidth devices, such as USB docking stations or HD cameras.
1x US234 2 x 4 USB 3.2 Gen1 Peripheral Sharing Switch
2x LIN6-11C1-E11G USB 3.2 Gen1 Type-B to Type-A Cables (1,2m)
1x Remote Port Selector
1x User Instructions

Specifications

Ports & interfaces
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity 4
USB 2.0 ports quantity 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity 2
Performance
LED indicators Yes
Housing material Plastic
Maximum data transfer rate 5 Gbit/s
Remote control function Yes
Product colour Black
Power connector Micro-USB Type-B
Design
Product colour Black
Technical details
Housing material Plastic
Indication
LED indicators Yes
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 0 - 80%
Weight & dimensions
Width 93 mm
Depth 93.7 mm
Height 26.8 mm
Weight 258 g
Package weight 392 g
Package width 70 mm
Package height 195 mm
Package depth 163 mm
Packaging content
Cables included USB
Quick start guide Yes
Packaging data
Package weight 392 g
Package width 70 mm
Package height 195 mm
Package depth 163 mm
Logistics data
Products per master (outer) case 10 pc(s)
Master (outer) case width 395 mm
Master (outer) case gross weight 4.64 kg
Master (outer) case length 405 mm
Master (outer) case height 182 mm
Master (outer) case net weight 2.58 kg
Brand
ATEN
SKU
US234-AT
