ATEN 2-Port True 4K DisplayPort MST Hub

ATEN

ATEN 2-Port True 4K DisplayPort MST Hub

Read reviews
SKU: VS92DP-AT
Your price $165.00
GST included · AUD
New Sealed in box Australian stock Warehouses in Sydney, Melbourne, Brisbane, Adelaide and Perth Delivery only - Pickup unavailable 2-5 Business days metro delivery. Australian manufacturer Warranty

In stock — ready to ship

Estimate shipping

Enter an Australian postcode for a quick estimate.

Final shipping options and price are confirmed at checkout.

  • Local Australian stock
  • Australian manufacturer warranty
  • GST included
  • Secure checkout

Need bulk pricing for schools or councils? Request a quote via Contact Us.

2-Port True 4K DisplayPort MST Hub

Key Features

  • Distributes one True 4K source to two DisplayPort displays at the same time
  • Allows for Single Stream Transport (SST) or Multi-Stream Transport (MST) Mode
  • Supports 4K resolution for dual output – up to 3840 x 2160@30Hz (4:4:4)
  • DisplayPort 1.2; HDCP 1.3 compliant
  • Provides Dolby TrueHD and DTS-HD Master 7.1 Audio channel
  • High quality and durable aluminum enclosure

Description

Designed with a cost effective, yet advanced DisplayPort MST solution in mind, the ATEN VS92DP 2-Port True 4K DisplayPort MST Hub allows the high-defi nition video to be transmitted to two different locations without losing quality. Productivity is enhanced with its feature that permits up to two displays to be connected to a Windows-based laptop / PC. Meanwhile, users can mirror the same image onto two displays or display independent content to each display for multitasking.
1x VS92DP 2-Port True 4K DisplayPort MST Hub
1x USB Type-A to USB Micro-B cable
1x user instructions

Specifications

Ports & interfaces
Video ports quantity 2
Video port type DisplayPort
Video out 2x DisplayPort
Cable length 0.15 m
Features
Housing material Aluminium
LED indicators Status
Maximum resolution 3840 x 2160 pixels
HDCP Yes
Product colour Black
Cable length 0.15 m
HD type 4K Ultra HD
HDCP version 1.3
Power
Power consumption (max) 2 W
Weight & dimensions
Weight 120 g
Width 60 mm
Depth 88 mm
Height 150 mm
Package weight 200 g
Package depth 119 mm
Package width 59 mm
Package height 160 mm
Packaging data
Package weight 200 g
Package depth 119 mm
Package width 59 mm
Package height 160 mm
Quantity per pack 1 pc(s)
Operational conditions
Operating temperature (T-T) 0 - 40 °C
Storage temperature (T-T) -20 - 60 °C
Operating relative humidity (H-H) 0 - 80%
Video
Maximum resolution 3840 x 2160 pixels
HDCP Yes
Colour
Product colour Black
Indication
LED indicators Status
Technical details
Housing material Aluminium
Video out 2x DisplayPort
Package width 59 mm
Package height 160 mm
Logistics data
Quantity per pack 1 pc(s)
Master (outer) case width 315 mm
Master (outer) case length 490 mm
Master (outer) case height 338 mm
Master (outer) case gross weight 2.34 kg
Products per master (outer) case 10 pc(s)
Master (outer) case net weight 1.2 kg
Harmonized System (HS) code 85176990
Brand
ATEN
SKU
VS92DP-AT
