Atdec AD-WF-10090 TV mount Black

<100 kg, VESA 100x200 - 900x600

Key Features

• Large heavy displays & touchscreens
• Installer-first design for safe trouble-free use
• Robust functionality & long service life
• Assurance of a high-quality respected brand

Description

Fixed-angle wall mount, max. 220lb (100kg). For mounting large heavy displays. Mounts large and heavy displays parallel to the wall, with multiple features to make installation easy and confident. This mount is for universal application in commercial, domestic, and light industrial environments. AD-WF-10090 supports displays to 220lb (100kg) with universal VESA 100x200 to 900x600. The large display will mount with a low profile to wall of just 1.3” (32mm). Installers can use integrated lateral shift capability to position the display precisely as desired. Other installation optimizations include spring-loaded locking tabs for quick display attachment, forgiving slotted mounting holes, and magnetic tipped display release cords (concealable). AD-WF-10090 suits most wall types (with appropriate hardware*).

Specifications

Mounting
Mounting type	Wall
Maximum weight capacity	100 kg
Panel mounting interface	100 x 200,200 x 200,200 x 300,200 x 400,200 x 600,300 x 200,300 x 300,400 x 200,400 x 300,400 x 400,400 x 600,600 x 200,600 x 400,800 x 200,800 x 400,800 x 600,900 x 600
Minimum VESA mount	100 x 200 mm
Maximum VESA mount	900 x 600 mm
Ergonomics
Distance to the wall (min)	3.2 cm
Distance to the wall (max)	3.2 cm
Easy to adjust	Yes
Design
Product colour	Black
Housing material	Steel
Technical details
Mounting type	Wall
Packaging content
Number of mounting brackets	2
Number of bolts	20
Mounting brackets included	Yes
Bolts included	Yes
Weight & dimensions
Width	1003 mm
Height	630 mm
Packaging data
Package width	416.6 mm
Package depth	1115.1 mm
Package height	40.6 mm
Package weight	5.31 kg
Logistics data
Master (outer) case width	431.8 mm
Master (outer) case length	1130.3 mm
Master (outer) case height	180.3 mm
Master (outer) case gross weight	24.9 kg
Products per master (outer) case	4 pc(s)
Other features
Mounting type	Wall
