Intel Core Ultra 5 225H (18MB Cache), 16GB DDR5-SDRAM, 512GB SSD, 14" WUXGA 1920 x 1200, Intel Arc 130T, LAN, WLAN, Webcam, Windows 11 Pro 64-bit
Key Features
- Windows 11 Pro 64-bit
- Intel Core Ultra 5 225H (18MB Cache)
- 14" WUXGA 1920 x 1200
- 16GB DDR5-SDRAM & 512GB SSD
Description
AI PC, configured for youASUS ExpertBook B3 AI PC offers extensive customization to empower your daily business needs. Equipped with up to the latest Intel® Core™ Ultra processor with Intel vPro®, Intel AI Boost NPU and Intel Arc graphics, this AI PC delivers solid performance to tackle a wide range of tasks seamlessly. ASUS ExpertBook B3 features AI tools such as ASUS AI ExpertMeet1, Microsoft Copilot2 and AI noise-canceling technology, delivering an unmatched productivity experience. With military-grade durability3, a full range of I/O ports, ultra-fast Wi-Fi and advanced security features, this lightweight AI PC ensures flexibility and efficiency on the go. In addition, with long battery life, exceptional visuals and audio, and an eco-friendly design, ASUS ExpertBook B3 supports a sustainable, streamlined workflow — keeping you productive wherever you work.
Specifications
| Design |
|---|
| Colour name |
Gentle Grey |
| Product type |
Laptop |
| Product colour |
Grey |
| Form factor |
Clamshell |
| Market positioning |
Work |
| Housing material |
Aluminium |
| Display |
|---|
| HD type |
WUXGA |
| Display diagonal |
35.6 cm (14") |
| Display resolution |
1920 x 1200 pixels |
| Touchscreen |
No |
| Display brightness |
300 cd/m² |
| Anti-glare screen |
Yes |
| RGB colour space |
NTSC |
| Colour gamut |
45% |
| Native aspect ratio |
16:10 |
| Processor |
|---|
| Processor generation |
Intel Core Ultra (Series 2) |
| Processor family |
Intel Core Ultra 5 |
| Processor model |
225H |
| Processor boost frequency |
4.9 GHz |
| Processor cores |
14 |
| Processor threads |
14 |
| Processor cache |
18 MB |
| Processor manufacturer |
Intel |
| Processor base power |
28 W |
| Maximum turbo power |
115 W |
| Efficient-core base frequency |
1.3 GHz |
| Performance-core base frequency |
1.7 GHz |
| Efficient-core Max Turbo Frequency |
4.3 GHz |
| Performance-core Max Turbo Frequency |
4.9 GHz |
| Performance cores |
4 |
| Efficient cores |
8 |
| Low Power Efficient-core Base Frequency |
700 MHz |
| Low Power Efficient-core Max Turbo Frequency |
2.5 GHz |
| Low Power Efficient-cores |
2 |
| Neural processor unit (NPU) |
|---|
| Neural processor unit (NPU) |
Intel AI Boost |
| Sparsity support |
Yes |
| Windows Studio effects support |
Yes |
| AI software frameworks supported by NPU |
DirectML, OpenVINO, Windows ML, ONNX RT, WebNN |
| Total processor performance up to |
83 TOPs |
| NPU performance up to |
13 TOPs |
| GPU performance up to |
63 TOPs |
| Memory |
|---|
| Internal memory |
16 GB |
| Internal memory type |
DDR5-SDRAM |
| Memory slots |
2x SO-DIMM |
| Maximum internal memory |
64 GB |
| Memory form factor |
SO-DIMM |
| Storage |
|---|
| SSD form factor |
M.2 |
| Optical drive type |
No |
| Total storage capacity |
512 GB |
| Storage media |
SSD |
| Number of SSDs installed |
1 |
| SSD capacity |
512 GB |
| SSD interface |
PCI Express 4.0 |
| Card reader integrated |
Yes |
| Compatible memory cards |
MicroSD (TransFlash) |
| Total SSDs capacity |
512 GB |
| NVMe |
Yes |
| Graphics |
|---|
| Discrete graphics card |
No |
| On-board graphics card family |
Intel Arc Graphics |
| On-board graphics card model |
Intel Arc 130T |
| Discrete graphics card model |
Not available |
| On-board graphics card |
Yes |
| On-board GPU manufacturer |
Intel |
| Audio |
|---|
| Built-in microphone |
Yes |
| Camera |
|---|
| Front camera |
Yes |
| Privacy camera |
Yes |
| Privacy type |
Privacy shutter |
| Front camera HD type |
Full HD |
| Infrared (IR) camera |
Yes |
| Windows Hello |
Yes |
| Optical drive |
|---|
| Optical drive type |
No |
| Network |
|---|
| Mobile network connection |
No |
| Top Wi-Fi standard |
Wi-Fi 6E (802.11ax) |
| Bluetooth |
Yes |
| Wi-Fi standards |
Wi-Fi 6E (802.11ax) |
| Ethernet LAN |
Yes |
| Ethernet LAN data rates |
1000 Mbit/s |
| Bluetooth version |
5.4 |
| Antenna type |
2x2 |
| Ports & interfaces |
|---|
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity |
2 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity |
0 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity |
2 |
| USB Type-C DisplayPort Alternate Mode |
Yes |
| USB 2.0 ports quantity |
0 |
| HDMI ports quantity |
1 |
| HDMI version |
2.1 |
| Ethernet LAN (RJ-45) ports |
1 |
| Combo headphone/mic port |
Yes |
| USB Power Delivery (USB PD) |
Yes |
| Keyboard |
|---|
| Pointing device |
Touchpad |
| Numeric keypad |
No |
| Spill-resistant keyboard |
Yes |
| Keyboard backlit |
Yes |
| Software |
|---|
| Operating system installed |
Windows 11 Pro |
| Operating system architecture |
64-bit |
| Battery |
|---|
| Battery technology |
Lithium-Ion (Li-Ion) |
| Number of battery cells |
3 |
| Battery capacity |
63 Wh |
| Power |
|---|
| AC adapter power |
65 W |
| AC adapter frequency |
50 - 60 Hz |
| AC adapter input voltage |
100 - 240 V |
| AC adapter output current |
3.25 A |
| AC adapter output voltage |
20 V |
| USB Power Delivery (USB PD) |
Yes |
| USB Type-C charging port |
Yes |
| USB Type-C required charging power (min) |
55 W |
| USB Type-C required charging power (max) |
65 W |
| Security |
|---|
| Cable lock slot |
Yes |
| Cable lock slot type |
Kensington |
| Fingerprint reader |
Yes |
| Trusted Platform Module (TPM) |
Yes |
| Password protection |
Yes |
| Password protection type |
BIOS, User, HDD |
| Windows Hello |
Yes |
| Trusted Platform Module (TPM) version |
2.0 |
| Certificates |
|---|
| Compliance certificates |
REACH |
| Sustainability |
|---|
| Sustainability certificates |
TCO, EPEAT Gold, EPEAT Climate +, ENERGY STAR, Forest Stewardship Council (FSC) Recycled |
| Weight & dimensions |
|---|
| Width |
315.1 mm |
| Depth |
226.8 mm |
| Height (front) |
1.89 cm |
| Height (rear) |
1.9 cm |
| Packaging data |
|---|
| AC adapter included |
Yes |
| Packaging content |
|---|
| AC adapter included |
Yes |
| Technical details |
|---|
| Sustainability certificates |
TCO, EPEAT Gold, EPEAT Climate +, ENERGY STAR, Forest Stewardship Council (FSC) Recycled |
| Compliance certificates |
REACH |
| Other features |
|---|
| On-board graphics card |
Yes |
| AC adapter included |
Yes |
| Anti-glare screen |
Yes |
